iCarsoft CR MAX - Page 14

6
Connectivity
 Mini USB 2.0
 USB 2.0
 Wi-Fi
Bluetooth
 OBD II
Body Color
Black
Audio Input/
Output
 Input: N/A
 Output: Buzzer & Speaker
Power and
Battery
 OBD DLC Voltage Range:9-18V
3.7V/5000mAh lithium-polymer battery
 Charges via 5 VDC power supply
Tested Battery
Life
Around 5 hours of continuous use
Battery Charging
Input
5 V/2 A
Power
Consumption
500mA (LCD on with default brightness, Wi-Fi
on) @3.7 V
Operating Temp.
0 to 50°C (32 to 122°F)
Storage Temp.
-20 to 70°C (-4 to 158°F)
Operating
Humidity
5% - 95% non-condensing
Dimensions (W x
H x D)
240.0mm*150.0mm*35.0mm
Net Weight
750 g
Supported
Automotive
Protocols
ISO9141-2, ISO14230-2,ISO15765, K/L-Line,
Flashing Code, SAE-J1850 VPW, SAE-J1850
PWM, ISO11898(Highspeed, Middlespeed,
Lowspeed and Singlewire CAN, fault-tolerant
CAN), SAE J2610,GM UART,UART Echo
Byte Protocol, Honda Diag-H Protocol, TP2.0,
TP1.6
