72
Figure 5-50 Sample Sensor ID Input Screen
3) Continue to select tire position and enter sensor IDs. A message
will display when the entered IDs have been registered to the
NOTE
The vehicle must remain stationary for at least 15 minutes with the
ignition off, this will place the sensors into sleep mode. The vehicle
must be driven for at least 15 minutes at a speed higher than 20 kph
to ensure the module has learned the sensor identifications and
For other services, please follow the on-screen instructions to
On completion of the drive cycle, carry out the tire pressure monitor
system test application.
5.12 Gearbox Reset
After the gearbox is disassembled or repaired, it will cause shift
delay or shock problems. At this time, this function needs to be
executed to make the gearbox automatically compensate according
to the driving conditions in order to achieve a more comfortable and
more ideal shift quality.
