Warning label (versions with built-in battery charger):
Afxed to the appliance in order to warn the operator to read the user and maintenance manual (this document) before
using the appliance. It also contains a summary of the procedures to be applied in order to properly charge the batteries.
Warning label (versions with built-in battery charger):
Used on the appliance to advise the operator of the procedures to be applied in order to properly care for the appliance.
Solution tank lter daily care warning label:
Afxed to the appliance in order to remind the operator to clean the solution tank lter after each use of the appliance.
Main switch symbol:
Located on the rear part of the appliance, to indicate the main switch.
Symbol of battery charge level:
Used on the instrument panel, to indicate the battery charge level display.
Symbol of brush gearmotor control switch:
Used on the instrument panel to indicate the brush gearmotor control switch.
Symbol of vacuum motor control switch:
Used on the instrument panel to indicate the vacuum motor control switch.
Symbol of solenoid valve control switch:
Used on the instrument panel to indicate the control switch for the solenoid valve tted in the brush head unit.
SYMBOLS USED ON THE INSTRUMENT PANEL (version Scrub 50D)
SYMBOLS USED ON THE INSTRUMENT PANEL (versions Scrub 50C-50O-55D-65D)
Main switch symbol:
Located on the rear part of the appliance, to indicate the main switch.
Traction motor potentiometer symbol:
Used on the control panel to indicate the knob that commands the potentiometer that controls the traction motor.
Symbol for ECO-MODE program:
Used on the control panel to indicate the switch for activating the ECO-MODE program.
Symbol of the reverse movement selector:
Used on the control panel to indicate the button for engaging the reverse gear.
Brush release symbol:
Used on the control panel to indicate the button for releasing the brush automatically.
Warning label (versions without built-in battery charger):
Afxed to the appliance in order to warn the operator to read the user and maintenance manual (this document) before using
the appliance. It also shows certain procedures to be applied for the proper care of the appliance.
