9
TECHNICAL DATA (SCRUB 55 - 65) U/M
SCRUB 55D SCRUB 65D
Rated power of the device W 1415
Working width mm 560 655
Working capacity up to m
2
/h 1960 2295
Maximum gradient with full load % 10
Standard squeegee width mm 800
Disc brush (number / diameter) No. / Ø mm 2 / 290 2 / 340
Disc brush rotations rpm 240
Brush head motor (Nominal power rating / Voltage) W / V 400 / 24
Maximum weight exerted upon the brush head unit kg 25 30
Maximum weight exerted upon the brush head unit (PM versions) kg 35 40
Front wheel [number / (diameter / width)] no. / (Ø mm / mm) 2 / (175-60)
Traction motor (Nominal power rating / Voltage) W / V 180
Maximum forward speed Km/h 3.5
Maximum reverse speed Km/h 2.2
Vacuum motor (Nominal power rating / Voltage) W / V 420 / 24
Suction vacuum (hole Ø 0 measured at the motor) mmH
2
O 1240
Solution tank capacity l 62
Recovery tank capacity l 66
Appliance length mm 1190 1220
Appliance height mm 1050
Appliance width (without squeegee) mm 620 695
Device width (with squeegee) mm 800
Device wheel track mm 465
Device pitch mm 270
Battery compartment dimensions (Height - Width - Length) mm 285 - 350 - 355
Voltage and nominal capacity of the recommended battery V/Ah 12 / 112
Device weight (with tanks empty and without batteries) kg 92 95
Individual battery weight kg 38
Device transport weight (device + batteries) kg 168 171
Gross weight of the device ready for use kg 237 240
Sound pressure level (ISO 11201) - L
pa
dB (A) 66
Uncertainty K
pa
dB (A) 1.5
Hand vibration level (ISO 5349) m/s
2
<2.5
Vibration measurement uncertainty 1.5%
