8 9
TECHNICAL DATA (SCRUB 50) U/M
SCRUB 50D SCRUB 50C SCRUB 50O
Rated power of the device W 920 1200 1000
Working width mm 508 500 508
Working capacity up to m
2
/h 1250 1750 1780
Maximum gradient with full load % 2 10 10
Standard squeegee width mm 700
Disc brush (number / diameter) No. / Ø mm 1 / 508 - -
Disc brush rotations rpm 140 - -
Brush head motor (Nominal power rating / Voltage) W / V 500 / 24 600 / 24 400 / 24
Cylindrical brush (number / (diameter - length)) No. / (Ø mm - mm) - 2 / (110 - 500) -
Cylindrical brushes rpm rpm - 700 -
Rectangular pad (number / (width / depth)) No. / (mm - mm) - - 1 / (508 / 355)
Orbital revolutions rpm - - 2300
Maximum weight exerted upon the brush head unit kg 23 25 25
Front wheel [number / (diameter / width)] no. / (Ø mm / mm) 2 / (175-60)
Traction motor (Nominal power rating / Voltage) W / V - 180 180
Maximum forward speed Km/h - 3.5 3.5
Maximum reverse speed Km/h - 2.2 2.2
Vacuum motor (Nominal power rating / Voltage) W / V 420 / 24
Suction vacuum (hole Ø 0 measured at the motor) mmH
2
O 1240
Solution tank capacity l 40
Recovery tank capacity l 60
Appliance length mm 1177 1156 1071
Appliance height mm 992 1009 1009
Appliance width (without squeegee) mm 591 612 591
Device width (with squeegee) mm 700
Battery compartment dimensions (Height - Width - Length) mm 285 - 350 - 355
Voltage and nominal capacity of the recommended battery V/Ah 12 / 112
Device weight (with tanks empty and without batteries) kg 80 90
Individual battery weight kg 38
Device transport weight (device + batteries) kg 156 166
Gross weight of the device ready for use kg 196 206
Sound pressure level (ISO 11201) - L
pa
dB (A) 66 <70 66
Uncertainty K
pa
dB (A) 1.5 1.5 1.5
Hand vibration level (ISO 5349) m/s
2
<2.5 <2.5 <2.5
Vibration measurement uncertainty 1.5% 1.5% 1.5%
