Icom IC-2200H - Specifications

88
14
SPECIFICATIONS
13
14
GENERAL
• Frequency coverage : (unit: MHz)
USA, Asia, Australia Tx: 144–148/Rx: 118–174*
Europe Tx: 144–146/Rx: 118–174*
Europe-1, Taiwan, Korea Tx/Rx: 144–146
*Guaranteed: 144–148 MHz range only.
• Type of emission : FM, AM (Receive only)
• Number of memory channels : 207 (incl. 6 scan edges and 1 call)
• Frequency resolution : 5, 10, 12.5, 15, 20, 25, 30, 50 kHz
• Operating temperature range : –10°C to +60°C; +14˚F to +140˚F
• Frequency stability : ±10 ppm (–10°C to +60°C)
• Power supply requirement : 13.8 V DC ±15%
• Current drain (at 13.8 V DC: approx.):
Transmit at 65 W 15 A
Receive standby 0.8 A
max. audio 1.0 A
• Antenna connector : SO-239 (50 Ω)
• Dimensions
(proj. not included) : 140(W) × 40(H) × 146(D) mm
5
1
⁄2(W)×1
9
⁄16(H)×5
3
⁄4(D) in
• Weight (approx.) : 1.25 kg; 2 lb 12 oz
TRANSMITTER
• Modulation system : Variable reactance frequency mod.
• Output power :
(*approx.,
†
Korea version)
• Max. frequency deviation : ±5.0 kHz [Wide]/±2.5 kHz [Narrow]
‡
• Spurious emissions : Less than –60 dBc
• Microphone connector : 8-pin modular (600 Ω)
RECEIVER
• Receive system : Double-conversion superheterodyne
• Intermediate frequencies : 1st: 21.7 MHz, 2nd: 450 kHz
• Sensitivity (at 12 dB SINAD) : 0.14 µV typical
• Squelch sensitivity (threshold) : 0.1 µV typical
• Selectivity :
[Wide] More than ±6 kHz/6 dB
Less than ±14 kHz/60 dB
[Narrow]
‡
More than ±3 kHz/6 dB
Less than ±9 kHz/55 dB
• Spurious and image rejection : 75 dB typical
• AF output power (at 13.8 V DC) : More than 2.4 W at 10% distortion with
an 8 Ω load
• Ext. speaker connector : 3-conductor 3.5 (d) mm (
1
⁄8″)/8 Ω
• Ext. Data connector : 3-conductor 2.5 (d) mm (
1
⁄8″)
‡
Some version only
All stated specifications are subject to change without notice or obligation.
Power output
Taiwan
65 W (50 W
†
)24W
25 W* 10 W*
10 W* N/A
5W* 5W*
Power
Selection
High
Middle
Mid. low
Low
