REPEATER OPERATION
4
■ Reversed duplex mode
When the reversed duplex mode is selected, the receive fre-
quency shifts.
(Transmit frequency shifts in normal duplex mode.)
Each receive and transmit frequency is shown in the table
below with the following conditions;
Input frequency : 145.30 MHz
Direction : – (negative)
Offset frequency : 0.6 MHz
q Push [SET ] to enter set mode.
w Push [SET] or [MONI] several times until the “REV” dis-
play appears as shown below.
e Rotate [DIAL] to turn the reversed duplex mode ON or
OFF.
r Push any key other than [SET] or [MONI] to exit set mode.
z Push [
SET B(D-OFF)] to enter set mode.
x
Push [ SET B(D-OFF)] or [ ENT C(T-OFF)] until
“REV” appears.
c Push [
YY
] or [
ZZ
] to set the reversed duplex
mode ON and OFF.
v Push [
CLR A(MW)] to exit set mode.
LOCK
S E T
ANM
MONI
DUP
LOW
T
-
SCAN
TONE
PRIO
M/CALL
SCAN
V/MHz
DIGITAL
PRIO
AO
BUSY
MUTE
NAR
MID
LOW
Push
SET
B
LOCK
S E T
ANM
MONI
DUP
LOW
T
-
SCAN
TONE
PRIO
M/CALL
SCAN
V/MHz
DIGITAL
PRIO
AO
BUSY
MUTE
NAR
MID
LOW
LOCK
USING
SET MODE
Reversed OFF ON
Rx frequency 145.30 MHz 144.70 MHz
Tx frequency 144.70 MHz 145.30 MHz
