PANEL DESCRIPTION
Key flow chart for the default setting
i MICROPHONE CONNECTOR
Connect the supplied microphone or optional DTMF micro-
phone.
NEVER connect non-specified microphones. The pin
assignments may be different and the transceiver may
be damaged.
DD
MICROPHONE
The supplied microphone has a PTT switch and a hanger
hook.
• The following functions are available when the microphone is on or
off hook:
(The optional CS-400PRO
CLONING SOFTWARE
is required.)
- Automatic scan start when on hook.
- Automatic priority channel selection when off hook.
- Sets to ‘Inaudible’ condition (mute condition) when on hook.
- Sets to ‘Audible’ condition (unmute condition) when off hook.
Normal mode
Function mode
Set mode
: Set the desired level/mode.
: Change the individual setting.
/
: Change the common setting.
: Push to enter channel bank selection mode.
Push for 1 sec. to enter Normal mode.
: Turn the function ON and OFF.
: [CH Up] : [ID-MR Select]
: [Bank/Func]
: [CONT/SGL]
: [Call]
: [CH Down]
: [CH Up] : [Scan Start/Stop]
: [Bank/Func]
: [Dup/Pri]
: [Moni(Audi)]
: [CH Down]
Push [
O
] for 1 sec.
Push [
O
] for 1 sec.
Push [ ] to turn power ON.
