Icom IC-7300 - TX Function; D TX Monitor Function; Monitor Function

4
RECEIVING AND TRANSMITTING
4-8
∂TX function
The ∂TX function shifts the transmit frequency up to
. kH without shifting the receive frequency.
1. Push
TX
.
• The ∂TX function turns ON.
LPushing
TX
turns the ∂TX function ON or OFF.
LWhile using the Fine Tuning function (p. 3-3), the ∂TX
frequency is displayed in 4 digits, instead of 3.
2. Set the ∂TX frequency to match the receiving
station’s frequency.
∂TX frequency
LTo reset the ∂TX frequency to “0.00,” hold down
CLEAR
for 1 second.
LYou can add the frequency shift to the operating
frequency by holding down
TX
for 1 second.
3. After communicating, push
TX
to turn the ∂TX
function OFF.
D ∂TX monitor function
When the ∂TX function is ON, you can directly monitor
the operating frequency by holding down
XFC
.
Rotate
Set ∂TX
frequency.
While holding down
XFC
.
Monitor function
The Monitor function enables you to monitor your
transmit audio. Use this function to check the
voice characteristics while adjusting transmit audio
parameters.
LYou can hear the CW sidetone regardless of the Monitor
function setting.
1. Select the mode that you want to monitor.
  ([DPSOH86%
2. Push
FUNCTION
.
• Opens the FUNCTION screen.
3. Touch [MONI] to turn ON the Monitor function.
LTouching [MONI] turns the Monitor function ON or OFF.
)81&7,21VFUHHQ86%PRGH
4. Touch [MONI] for 1 second.
5. Adjust MONITOR to the clearest audio output
between 0 and 100 , while speaking at your
normal voice level.
NOTE When using the VOICE DELAY (p. 4-7), turn OFF
the Monitor function. Otherwise the transmitted audio will
echo.
Rotate
Push
