PANEL DESCRIPTION
n Front panel (Continued)
t MEMORY SWITCH [MEM]
Hold down for 2 seconds to program a displayed fre-
quency to any blank regular memory channel or delete/
revive the selected memory channel (depending on the
operating mode) (p. 9).
y RECALL SWITCH [RCL]
➥ Push to enter/exit the memory mode (p. 9).
➥ Hold down for 2 seconds to enter/exit the menu mode
(p. 20).
u LIGHT-SENSITIVE DETECTOR
This detector senses ambient light. The detector is used
to adjust “Dimmer brightness (Low/High)” (p. 23) auto-
matically when the “Dimmer Mode” (p. 23) is set to ‘AUTO.’
i INNER (Small) TUNING DIAL [DIAL]
➥ Rotate to set the standby frequencies (kHz digit)
(p. 5), memory channels (p. 10), MENU mode settings
(p. 20).
➥ Hold down for 2 seconds to turn the dial/panel lock
function ON (p. 18).
o OUTER (Large) TUNING DIAL [O-DIAL]
Rotate to set the standby frequency (MHz digit) (p. 5),
group memory channel (p. 13), cursor position (p. 15).
RCL
MEM
OFF
VOL
PUSH
TEST
COMM
DUAL
EC
iA210E
CH09 SAMPLE
121.525
118.00
RX
MEMORY
e ytr iouqw
