Icom IC-A210E - CLONING AND OPTIONS; Data Transfer and Optional Accessories

26
6
CLONING
D Data cloning
Cloning allows you to quickly and easily transfer the
programmed contents or data from a PC to a transceiver
using the optional CS-A210 CLONING SOFTWARE.
Data can be cloned to and from a PC (IBM compatible)
using the optional CS-A210 CLONING SOFTWARE and the op-
tional OPC-1529R CLONING CABLE (connect with the data jack).
Consult the CS-A210 instruction manual and HELP file for
details.
D Displayed Message
•Whileclonewriting.
•Whenclonewritingisnishedproperly.
•Whenclonewritingerroroccurs.
•Whileclonereading.
•Ifanerroroccurswhilecloning,thefollowingmessageap-
pears when the power is turned OFF and then ON. In this
case, re-cloning or re-writing the data correctly is neces-
sary to cancel the error.
CLONE
WRITE
CLONE
WRITE OK
CLONE
READ
CLONE
READ
127.00
RX
MEMORY
CLONE
NO DATA
CLONE
WRITE ERR
