MENU MODE
D Beep Tone Level “BEEP”
Confirmation beep tones normally sound when storing mem-
ory, operating time-out-timer function, etc. These can be set
the desired beep level as you prefer.
•OFF(0)  :ThebeeptoneturnsOFF.
•001to100 :Settingthebeeptonelevelfrom1to100.
D Intercom Usable Setting “INCOM MODE”
Set the intercom using or not.
•ON    :Theintercomisusable.
•OFF   :Theintercomisunusable.
D Time-Out-Timer “TIME OUT”
To prevent accidental prolonged transmission, the trans-
ceiver has a time-out-timer function. This timer starts when a
transmission begins, and will cut off the transmission when
the time set in the timer elapses.
•020to240 :Settingtime-out-timerstartingperiodfrom20sec-
onds to 240 seconds in 10 seconds intervals.
D Frequency Step “FREQ. STEP”
Set the desired frequency step: 8.33 kHz or 25 kHz.
•25kHz  :Settingthefrequencystepto25kHz.
•8.33kHz  :Settingthefrequencystepto8.33kHz.
D Interlock “INTERLOCK”
When two transceivers are connected together, the interlock
function can prevent them from transmitting at the same
time.
•TXINHIBIT :Transmissionisprevented.
•RXMUTE :Audiooutputisprevented.
•BOTH  :Transmissionandaudiooutputarebothprevented.
D Memory Clear “MEM CLEAR”
Set values in the CPU are cleared.
Hold down [MEM] for 2 seconds, the CPU is reset as fol-
lows.
•MENU  :MENUmodeitemsarereset.
•MEMORY :Storedmemoriesarereset.
•ALL   :AllCPUdataisreset.
05
NOTE: When using an external speaker, the beep tone
level when the squelch is closed is fixed and cannot be
changed in the MENU mode.
NOTE: The interlock does not appear when the “TX/RX
INTERLOCK SW” is set to “DISABLE,” by the CS-A210.
