MENU MODE
D Sidetone Level “SIDETONE LV”
When using an optional headset (supplied from third party*)
via the adapter, the transceiver outputs your transmitted
voice to the headset for monitoring.
*Ask your dealer in details.
•OFF(0) :ThesidetonefunctionisOFF.
•001to080 :Setsthesidetonelevelfrom1to80.
D Transmitting Microphone Selection
“TX MIC SEL”
Set the active microphone when pushing microphone’s PTT
switch.
The item allows you to control which connected microphone
is permitted to transmit.
•MIC1 :Selectsmicrophone1.
•MIC2 :Selectsmicrophone2.
•MIC1+2 :Selectsbothmicrophone1andmicrophone2.
D Dimmer Mode “DISP MODE”
The light sensor which is built into the display is used for this
function.
Set the OLED dimmer mode.
•OFF :ThedimmerfunctionisOFF.
•AUTO :Setsthedimmerautomaticallydependingonlocal
brightness.
•MANUAL :SetsthedimmerdependingonDimmerBrightness
(Low) “DISP LOW.”
D Dimmer Brightness (Low) “DISP LOW”
Set the lower brightness level in the automatic adjustment
range when “AUTO” is selected at the “Dimmer Mode.”
The transceiver automatically adjusts its display brightness
by the current lighting conditions.
•OFF :ThekeybacklightsetsOFF.
•001to049 :Setsthelowdimmerbrightnesslevelfrom1to49.
D Dimmer Brightness (High) “DISP HIGH”
Set the upper brightness level in the automatic adjustment
range when “AUTO” is selected in the Dimmer Mode.
•050to100 :Setsthedimmerbrightnesslevelfrom50to100.
D Dimmer Brightness (Manually) “DISP MAN.”
Set the brightness manually to suit your own preferences.
•000to100 :Setsthedimmerlevelmanuallyfrom0(OFF)to100.
D Dimmer Response “DISP RESP.”
Set the dimmer switching speed when selecting “AUTO” at
the “Dimmer Mode.”
•STANDARD :Selectsnormalswitchingspeed.
•FAST :Selectsfastswitchingspeed.
