16
5
SCAN OPERATION
Scan types
The U.S.A. version has 3 scan types to suit your needs. The
non-U.S.A. versions have 2 scan types.
COM band scan
q Push [CLR•DEL] to select the frequency mode.
w Push [SQL•WX-ALERT], then rotate [DIAL] to set the
squelch level to the point where noise is just muted.
e Push , then push [ANL•SCAN] to start the scan.
When a signal is received, the scan pauses until it disappears.
To change the scanning direction, rotate [DIAL].
r To stop the scan, push [CLR•DEL].
Memory scan
q Push [MR•MW] to select the memory mode.
Push , then push [0•BANK], and rotate [DIAL] to select the
BANK number, if desired. Push [CLR•DEL] to exit the BANK se-
lection mode.
w Push [SQL•WX-ALERT], then rotate [DIAL] to set the
squelch level to the point where noise is just muted.
e Push , then push [ANL•SCAN] to start the scan.
When a signal is received, the scan pauses until it disappears.
To change the scanning direction, rotate [DIAL].
r To stop the scan, push [CLR•DEL].
NOTE: Program 2 or more memory channels to start the
memory scan.
WEATHER CHANNEL SCAN
Repeatedly scans all TAG weather channels. Weather
channels are available in the U.S.A. version only.
MEMORY SCAN
Repeatedly scans all
selected memory bank’s
“TAG” memory chan-
nels. Used for checking
often-used channels
and bypassing usually
busy channels such as
control-tower frequen-
cies.
COM BAND SCAN
108.000
MHz
Scan
Jump
118.000
MHz
136.9917
MHz
non-TAG
channel
non-TAG channel
Mch 2 Mch 4 Mch 6
Mch 7Mch 1
Mch 8Mch 10Mch 19
Repeatedly scans
all frequencies
over the entire
COM band.
