Icom IC-A24

iii
TABLE OF CONTENTS
FOREWORD ..................................................................................... i
IMPORTANT ...................................................................................... i
EXPLICIT DEFINITIONS ................................................................... i
SUPPLIED ACCESSORIES .............................................................. i
PRECAUTION .................................................................................. ii
TABLE OF CONTENTS ................................................................... iii
1 ACCESSORY ATTACHMENT .................................................... 1
2 PANEL DESCRIPTION ..........................................................2–7
Panel description
■
....................................................................2
Function display
■
......................................................................6
3 BASIC OPERATION .............................................................8–11
Setting a frequency
■
.................................................................8
Selecting a weather channel (U.S.A. version only)
■
.................8
Receiving
■
................................................................................9
ANL function
■
...........................................................................9
Channel spacing setting
■
..........................................................9
Setting a squelch level
■
............................................................9
Transmitting
■
.............................................................................9
Low battery indicator
■
.............................................................10
Recall function
■
......................................................................10
Setting weather alert function
■
...............................................11
Accessing the 121.5 MHz emergency frequency
■
..................11
Lock function
■
.........................................................................11
Side tone function
■
.................................................................11
Setting beep tone
■
..................................................................11
4 MEMORY OPERATION ...................................................... 12–15
Memory channel selection
■
....................................................12
Transferring memory contents
■
..............................................12
Programming a memory channel
■
..........................................13
Memory names
■
.....................................................................14
Clearing the memory contents
■
..............................................14
5 SCAN OPERATION ............................................................16–17
Scan types
■
............................................................................16
COM band scan
■
....................................................................16
Memory scan
■
........................................................................16
Weather channel scan (U.S.A. version only)
■
.........................17
“TAG” channel setting
■
............................................................17
6 VOR NAVIGATION (IC-A24 ONLY) ....................................18–24
VOR indicators
■
......................................................................18
VOR functions
■
.......................................................................19
Flying to a VOR station
■
.........................................................20
Entering a desired course
■
.....................................................22
Crosschecking position
■
.........................................................22
Duplex operation (U.S.A. version only)
■
.................................24
7 CLONING .................................................................................25
8 BATTERY PACKS ..............................................................26–29
Battery cautions
■
....................................................................26
Battery charging
■
....................................................................26
Optional battery case
■
............................................................27
Optional battery chargers
■
.....................................................28
9 SPECIFICATIONS ..............................................................30–31
10 OPTIONS ..................................................................................32
11 OPTIONAL HEADSET CONNECTION ....................................33
12 SAFETY TRAINING INFORMATION..................................34–35
13 FOR CLASS A UNINTENTIONAL RADIATORS ..................... 36
14 TROUBLESHOOTING .............................................................37
INDEX .......................................................................................38–39
