Icom IC-V8 User Manual

8
1
PANEL DESCRIPTION
o SIGNAL INDICATOR
Appears when the channel is busy and shows receiving signal
strength as below.
Weak ⇐ RX Signal level ⇒ Strong
!0 LOW POWER INDICATOR
Appears when low output power is selected. (p. 18)
!1 KEY LOCK INDICATOR (p. 19)
Appears when the key lock function is ON.
!2 FREQUENCY READOUT
Shows operating frequency, channel number or channel names,
depending on display mode (p. 20).
!3 MEMORY CHANNEL INDICATOR
Indicates the selected memory channel number or other items
such as the call channel, etc. (pgs. 19, 25)
!4 MEMORY MODE INDICATOR
Appears while in memory mode or channel number indication
mode. (p. 25)
!5 AUTO POWER OFF INDICATOR
Appears while the auto power OFF function is activated. (p. 50)

Icom IC-V8 Specifications

General

Frequency Range	136-174 MHz
Power Output	5.5 W
Mode	FM
Receiver Sensitivity	0.16 μV (12dB SINAD)
Channel Spacing	12.5/25 kHz
Voltage	7.2 V DC
