Battery charging
D Regular charging
with the BC-146
The optional BC-146 provides
regular charging of an optional
battery pack with/without
transceiver. The following is
additionally required:
• An optional AC adaptor.
(An AD-99 is supplied with
BC-146.)
D About AD-99
Attach the spacer (Spacer B/C)
to the adaptor (Spacer A) with
orientation as illustrated in the di-
agram below.
Attach the spacer (Spacer B/C) to
the adaptor with the orientation of
the stamp “ ” pointing up.
When removing the spacer
(Spacer B/C),
Push the notch
carefully with your finger to re-
move the spacer (Spacer B/C)
from the adapter (Spacer A).
R CAUTION!
DO NOT push or force the notch with a screw driver, etc., to remove it.
DO NOT bend the notch when the adapter and spacer are not joined
together. This will cause weakening of the notch plastic.
Both cases may break the notch and it may not be able to be reattached.
12
3
BATTERY PACKS
BC-146 + AD-99
Check orienta-
tion for correct
charging. (In-
sert together
with AD-99.)
Turn power OFF.
Check orientation
and
Spacer A
Spacer B/C
Remove the spacer
from the adapter.
Push the notch
carefully.
