OTHER FUNCTIONS
DD
Squelch delay
Selects squelch delay from short and long to
prevent repeated opening and closing of the
squelch during reception of the same signal.
• Sqt. S: The squelch closes in short delay.
(default)
• Sqt. L: The squelch closes in long delay.
DD
DTMF speed
The rate at which DTMF memories send indi-
vidual DTMF characters can be set to accom-
modate operating needs.
• 1: 100 msec. interval; 5.0 cps speed
(default)
• 2: 200 msec. interval; 2.5 cps speed
• 3: 300 msec. interval; 1.6 cps speed
• 5: 500 msec. interval; 1.0 cps speed (cps=characters/sec.)
DD
Dial assignment
Selects [VOL] control action from AF volume
and tuning dial.
• tOP.VO : AF volume
(default)
• tOP.dI : Tuning dial
DD
Display type
Selects LCD indication type from frequency,
channel number and channel names.
• dSP.FR : Shows frequency (default)
• dSP.CH : Shows channel number*
• dSP.Nm: Shows channel names
*Memory channels only can be selected.
