53
11
OTHER FUNCTIONS
DD
Mic simple mode
This item turns the microphone simple mode
ON and OFF. Microphone simple mode is
used to change the function assignments for
keys in the optional HM-75A
REMOTE CONTROL
SPEAKER
-
MICROPHONE
as below. This assign-
ment is convenient for 3-channel use of sim-
ple operation.
• mIC.N1 : Normal 1 (default)
• mIC.N2 : Normal 2
• mIC.Sm : Simple mode
NOTE:
Turn power OFF when connecting the HM-75A to the trans-
ceiver.
VFO mode cannot be selected via the microphone when SIM-
PLE mode is selected.
Optional HM-75A required
HM-75A
Mode NORMAL1 NORMAL2 SIMPLE
key
[A]
Freq. [B•
CALL
]
[SQL] [SQL]
CH Null
[B]
Freq. VFO/Memory VFO/Memory
[B•
CALL
]
CH Null Null
[∫]
Freq. Freq. Up Freq. Up
MR-00CH
CH Memory CH Up Memory CH Up
[√]
Freq. Freq. Down Freq. Down
MR-01CH
CH Memory CH Down Memory CH Down
To Next Page
