ICT Protege WX Configuration Guide

Input Number Description Type Group
CP001:21 Reserved - -
CP001:22 ModBUS Communication Fault Hardware Fault System
CP001:23 Protege System Remote Access Hardware Fault System
CP001:24 Installer Logged In Hardware Fault System
CP001:25 Reserved - -
CP001:26 Reserved - -
CP001:27 Reserved - -
CP001:28 Reserved - -
CP001:29 System restarted Hardware Fault System
CP001:30 Reserved - -
CP001:31 Reserved - -
CP001:32 3G Modem Link Lost (legacy 3G modem model only) Hardware Fault System
CP001:33 Controller Group Link Lost Hardware Fault System
| | | | | | | |
CP001:64 Reserved - -
One-Door Controllers
Input Number Description Type Group
CP001:02 12V Supply Failure Power Fault General
CP001:04 Real Time Clock Not Set RTC/Clock Loss General
CP001:05 Service Report Test - -
CP001:08 Auxiliary Failure Power Fault General
CP001:13 Module Communication Module Loss System
CP001:14 Module Network Security Module Security System
CP001:20 Report IP Reporting Failure Reporting Failure System
CP001:22 ModBUS Communication Fault Hardware Fault System
CP001:23 Protege System Remote Access Hardware Fault System
CP001:24 Installer Logged In Hardware Fault System
CP001:29 System restarted Hardware Fault System
CP001:30 PoE Connection Lost (legacy PoE model only) Power Fault General
CP001:31 Output Over-Current Failure (legacy PoE model only) Power Fault General
Protege WX Integrated System Controller | Configuration Guide 22

ICT Protege WX Specifications

General

Communication	Ethernet, RS-485
Operating Voltage	12V DC
Enclosure Rating	IP30
Input Voltage	12V DC
Operating Temperature	-10°C to +55°C
Protocol	Osdp, Wiegand
