One-Door Controllers
The following table indicates the position and resistor configuration corresponding to each input address for one-
door controllers:
Input Address Position Resistor
1 Z1 1K
2 Z1 2K4
3 Z2 1K
4 Z2 2K4
Trouble Inputs
Trouble inputs are used to monitor the status of the controller and in most cases are not physically connected to
an external input. These can then be used to report a message to a monitoring station, remote computer, keypad
or siren.
The following table details the trouble inputs that are configured in the controller and the trouble type and group
that they activate.
Two-Door Controllers
Input Number Description Type Group
CP001:01 Reserved - -
CP001:02 12V Supply Failure Power Fault General
CP001:03 Reserved - -
CP001:04 Real Time Clock Not Set RTC/Clock Loss General
CP001:05 Service Report Test - -
CP001:06 Service Report Failure to Communicate Reporting Failure General
CP001:07 Phone Line Fault (modem model only) Phone Line Lost General
CP001:08 Auxiliary Failure Power Fault General
CP001:09 Bell Cut/Tamper Bell/Output Fault General
CP001:10 Reserved - -
CP001:11 Bell Current Overload Bell/Output Fault General
CP001:12 Reserved - -
CP001:13 Module Communication Module Loss System
CP001:14 Module Network Security Module Security System
CP001:15 Reserved - -
CP001:16 Reserved - -
CP001:17 Reserved - -
CP001:18 Reserved - -
CP001:19 Reserved - -
CP001:20 Ethernet Link Lost Hardware Fault System
Protege WX Integrated System Controller | Configuration Guide 21
