ICT Protege WX Configuration Guide

Current Features
The current features of the Protege WX controllers include:
Features PRT-WX-DIN-IP PRT-WX-DIN PRT-WX-DIN-1D
Internal industry standard 10/100 ethernet
32 Bit RISC processor with 2GB total memory
Encrypted module network using RS-485 communication
NIST Certified AES 128, 192 and 256 Bit encryption
Factory loaded HTTPScertificate
OSDPconfigurable RS-485
Reader ports 2 2 1
High security monitored inputs 8 8 2
Open collector outputs 4 4 -
Form C Relay outputs 2 2 1
Bell Output
USB Port
Built-in offsite communications dialer
(Contact ID or SIA)
Industry standard DIN rail mounting
Protege WX Integrated System Controller | Configuration Guide 6

ICT Protege WX Specifications

General

Communication	Ethernet, RS-485
Operating Voltage	12V DC
Enclosure Rating	IP30
Input Voltage	12V DC
Operating Temperature	-10°C to +55°C
Protocol	Osdp, Wiegand
