Ideal Boilers LOGIC Code Combi 26 - Flue Terminal Position


INSTALLATION
Ideal Logic Code Combi - Installation and Servicing

rf8394-1
690mm
Fixed
300mm
min
28 FLUE TERMINAL POSITION
rf8393-1
300mm
min
300mm
min
625mm
Fixed
Flat roof - with structure


Pluming may occur at the termination so, where possible,
terminal positions where this could cause a nuisance
should be avoided.
Minimum dimensions are shown below
rf8392
Note.
The equivalent ue length
resistance of the elbow kits are:
90
o
elbow kit = 1m
45
o
elbow kit = 0.6m
Terminal Position Minimum Dimension
Directly below an opening,
  
Below plastic / painted gutters 300 mm
  
Below eaves or balcony 500 mm
Below velux windows 2000mm
  
RF9807
A
A
B
A
A = 600mm
B = 2000mm
The flue terminal shall not penetrate the shaded area of the roo
f
