IDEAL Evomax 30 Product Guide

19
SYSTEM DESIGN OPTIONS
TOTAL OUTPUT
REQUIRED KW
NO.
OF BOILERS
SIDE BY SIDE OPTION
– BOILER MODELS
SIDE BY SIDE
FOOTPRINT SIZE
W X D (MM)
HEADER KIT
PRODUCT NO.
SIDE BY SIDE
BOILER
MODELS
BACK TO BACK
FOOTPRINT SIZE
W X D (MM)
FRAME/
HEADER
PRODUCT NO.
BACK TO BACK
60 2 30 1480 x 552 209799 30 930x950 209901
70 2 30 + 40 1480 x 552 209799 30 + 40 930x950 209901
80 2 40 1480 x 552 209799 40 930x950 209901
90 2 30 + 60 1480 x 552 209799 30 + 60 930x950 209901
100 2 40 + 60 1480 x 552 209799 40 + 60 930x950 209901
110 2 30 + 80 1480 x 552 209799 30 + 80 930x950 209901
120 2 60 1480 x 552 209799 60 930x950 209901
130 3 30, 40 + 60 2030 x 552 209801 30, 40 + 60 480x950 209903
140 2 60 + 80 1480 x 552 209799 60 + 80 930x950 209901
150 3 30, 40 + 80 2030 x 552 209801 30, 40 + 80 480x950 209903
160 2 80 1480 x 552 209799 80 930x950 209901
170 3 30, 60 + 80 2030 x 552 209801 30, 60 + 80 480x950 209903
180 2 80 + 100 1480 x 573 209799 80 + 100 930x1096 209901
190 3 30, 60 + 100 2030 x 573 209801 30, 60 + 100 480x1096 209903
200 2 100 1480 x 573 209799 100 930x1096 209901
210 4 30, 40, 60 + 80 2580 x 552 209803
30, 40, 60
+ 80
1480x950 209905
220 3 2 x 60 + 100 2030 x 573 209801 2 x 60 + 100 1480x1096 209903
230 4 30, 40, 60 + 80 2580 x 573 209803
30, 40, 60
+ 100
1480x1096 209905
240 2 120 1480 x 663 209798 120 930x1276 209900
250 4 30, 60, 2 x 80 2580 x 552 209803 30, 60, 2 x 80 1480x950 209905
260 3 60, 2 x 100 2030 x 573 209801 60, 2 x 100 1480x1096 209903
270 2 120 + 150 1480 x 663 209798 120 + 150 930x1276 209900
280 3 80, 2 x 100 2030 x 573 209801 80, 2 x 100 1480x1096 209903
290 4 30, 60, 2 x 100 2580 x 573 209803 30, 60, 2 x 100 1480x1096 209905
300 2 150 1480 x 663 209798 150 930x1276 209900
310 4 30, 80, 2 x 100 2580 x 573 209803 30, 80, 2 x 100 1480x1096 209905
320 4 40, 80, 2 x 100 2580 x 573 209803 40, 80, 2 x 100 1480x1096 209905
330 4 30, 3 x 100 2580 x 573 209803 30, 3 x 100 1480x1096 209905
340 4 60, 80, 2 x 100 2580 x 573 209803 60, 80, 2 x 100 1480x1096 209905
350 5 30, 40, 80, 2 x 100 3130 x 573 209805
30, 40, 80,
2 x 100
2030x1096 209907
