FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 2-169
2: P RODUCT S PECIFICATIONS
■ Analog Output Specifications
■ Analog Input Specifications
Type No. FC6A-PK2AV FC6A-PK2AW
Output
Type and
Output
Range
Voltage 0 to 10V DC ―
Current ― 4 to 20mA DC
Load
Impedance 2 kΩ or higher 500 Ω or lower
Load Type Resistive load
DA
Conversion
DA Conversion Time Max 40 ms Max 20 ms
Output Update Interval 20 ms 20 ms
Total Output System Transfer Time DA conversion time + Output Update Interval + 1 scan time
Output
Error
Maximum Error at 25°C ±0.3% of full scale ±0.3% of full scale
Temperature Coefficient ±0.02% of full scale/°C ±0.02% of full scale/°C
Output Ripple Max 30 mV Max 30 mV
Overshoot 0% 0%
Data
Digital Resolution 4,096 steps (12 bits) 4,096 steps (12 bits)
Input Value per Step 2.44 mV (0 to 10 V) 3.91 µA (4 to 20 mA)
Data Type in Application Program 0 to 4,095 (0 to 10 V) 0 to 4,095 (4 to 20 mA)
Monotonicity Yes Yes
Current Loop Open ― Not detectable
Noise
Resistance
Maximum Temporary Deviation
during Electrical Noise Tests
Max ±4.0% of full scale Max ±4.0% of full scale
Recommended Cable Pair shielded cable
Crosstalk MAX 1 LSB MAX 1 LSB
Isolation None None
Effect of Improper Output Connection No damage No damage
Calibration or Verification to Maintain Rated
Accuracy
Not possible Not possible
Type No. FC6A-PJ2A FC6A-PJ2CP
Input Type Voltage Current Resistance Thermometer Thermocouple
Input Type and Input Range 0 to 10V DC
4 to 20mA DC
0 to 20mA DC
Pt100:
-200 to 850°C
(-328 to 1,562°F)
Pt1000:
-200 to +600°C
(-328 to 1,112°F)
Ni100:
-60 to +180°C
(-76 to 356°F)
Ni1000:
-60 to +180°C
(-76 to 356°F)
(K) -200 to 1,300°C (-328 to 2,372°F)
(J) -200 to 1,000°C (-328 to 1,832°F)
(R) 0 to 1,760°C (32 to 3,200°F)
(S) 0 to 1,760°C (32 to 3,200°F)
(B) 0 to 1,820°C (32 to 3,308°F)
(E) -200 to 800°C (-328 to 1,472°F)
(T) -200 to 400°C (-328 to 752°F)
(N) -200 to 1,300°C (-328 to 2,372°F)
(C) 0 to 2,315°C (32 to 4,199°F)
Input Impedance Min 1 MΩ Max 250 Ω Min 1 MΩ
Allowed Conductor Resistance ――Max 10 Ω―
Detected Input Current ――TYP: 0.2 mA Max 1.0 mA ―
AD
Conversion
Sampling Time 10 ms 10 ms 250 ms 250 ms
Sampling Repetition
Time
20 ms 500 ms
Total Input Delay
Time
*1
Sampling time + Sampling repetition time + 1 scan time
Type of Input Single-ended
Operation Mode Self-scan
Conversion Method SAR
