IDEC MICROSmart FC6A Series User Manual

2: P RODUCT S PECIFICATIONS
2-190 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Digital I/O
module
FC6A-N08B1/
FC6A-N08B4
55°C
8 inputs: 24V DC,
7 mA/PT
-
65°C
8 inputs: 24V DC,
7 mA/PT
Tota l Max. 28 mA, 4 PTs
-
FC6A-N16B1/
FC6A-N16B4
55°C
16 inputs, 24V DC,
7 mA/PT
Total max. 123.2 mA
-
65°C
16 inputs: 24V DC,
7 mA/PT
Total Max. 56 mA 8 PTs
-
FC6A-N16B3
55°C
16 inputs: 24V DC,
5 mA/PT
Tota l Max. 72 mA
-
65°C
16 inputs: 24V DC,
5 mA/PT
Tota l Max. 35 mA, 7 PTs
-
FC6A-N32B3
55°C
32 inputs: 24V DC,
5 mA/PT
Total Max. 144 mA
-
65°C
32 inputs: 24V DC,
5 mA/PT
Total Max. 70 mA, 14 PTs
-
FC6A-N08A11/
FC6A-N08A14
55°C
8 inputs: 120V AC,
50/60 Hz, 15 mA/PT
-
65°C
8 inputs: 120V AC,
50/60 Hz, 15 mA/PT
Tota l Max. 60 mA, 4 PTs
-
FC6A-R081/
FC6A-R084
55°C -
8 relay outputs:
240V AC/30V DC, 2 A (GEN/RES) 7 A/Common
65°C -
8 relay outputs:
240V AC/30V DC, 2 A (GEN/RES) 7 A/Common
Total Max. 8 A, 4 PTs
FC6A-R161/
FC6A-R164
55°C -
16 relay outputs:
240V AC/30V DC, 2 A (GEN/RES) 8 A/Common
65°C -
16 relay outputs:
240V AC/30V DC, 2 A (GEN/RES) 8 A/Common
Total Max. 16 A, 8 PTs
FC6A-T08P1/
FC6A-T08P4
55°C -
8 transistor source outputs:
24V DC, 0.5 A/PT
Class 2
65°C -
8 transistor source outputs:
24V DC, 0.5 A/PT
Class 2
Total Max. 2 A, 4 PTs
FC6A-T16P1/
FC6A-T16P4
55°C -
16 transistor source outputs:
24V DC, 0.5 A/PT
Class 2
65°C -
16 transistor source outputs:
24V DC, 0.5 A/PT
Class 2
Total Max. 4 A, 8 PTs
FC6A-T16P3
55°C -
16 transistor source outputs:
24V DC, 0.1 A/PT
Class 2
65°C -
16 transistor source outputs:
24V DC, 0.1 A/PT
Class 2
Total Max. 0.8 A, 8 PTs
FC6A-T32P3
55°C -
32 transistor source outputs:
24V DC, 0.1 A/PT
Class 2
65°C -
32 transistor source outputs:
24V DC, 0.1 A/PT
Class 2
Total Max. 1.6 A, 16 PTs
Model Names Type Air Temp Inputs Outputs
