FC6A S
ERIES
MICROS
MART
U
SER
’
S
M
ANUAL
FC9Y-B1722 2-191
2: P
RODUCT
S
PECIFICATIONS
Digital I/O
module
FC6A-T08K1/
FC6A-T08K4
55°C -
8 transistor sink outputs:
24V DC, 0.5 A/PT
Class 2
65°C -
8 transistor sink outputs:
24V DC, 0.5 A/PT
Class 2
Total Max. 2 A, 4 PTs
FC6A-T16K1/
FC6A-T16K4
55°C -
16 transistor sink outputs:
24V DC, 0.5 A/PT
Class 2
65°C -
16 transistor sink outputs:
24V DC, 0.5 A/PT
Class 2
Total Max. 4 A, 8 PTs
FC6A-T16K3
55°C -
16 transistor sink outputs:
24V DC, 0.1 A/PT
Class 2
65°C -
16 transistor sink outputs:
24V DC, 0.1 A/PT
Class 2
Total Max. 0.8 A, 8 PTs
FC6A-T32K3
55°C -
32 transistor sink outputs:
24V DC, 0.1 A/PT
Class 2
65°C -
32 transistor sink outputs:
24V DC, 0.1 A/PT
Class 2
Total Max. 1.6 A, 16 PTs
FC6A-M08BR1/
FC6A-M08BR4
55°C
4 inputs: 24V DC,
7 mA/PT
4 relay outputs:
240V AC/30V DC, 2 A (GEN/RES) 7 A/Common
65°C
4 inputs: 24V DC,
7 mA/PT
Total Ma x. 14 mA, 2 PTs
4 relay outputs:
240V AC/30V DC, 2 A (GEN/RES) 7 A/Common
Total Max. 4 A, 2 PTs
FC6A-M24BR1/
FC6A-M24BR4
55°C
16 inputs: 24V DC,
7 mA/PT
Total Max. 123.2 mA
8 relay outputs:
240V AC/30V DC, 2 A (GEN/RES) 7 A/Common
65°C
16 inputs: 24V DC,
7 mA/PT
Total Ma x. 56 mA, 8 PTs
8 relay outputs:
240V AC/30V DC, 2 A (GEN/RES) 7 A/Common
Total Max. 8 A, 4 PTs
Analog I/O
module
FC6A-J2C1/
FC6A-J2C4
55°C 2 analog inputs -
65°C 2 analog inputs -
FC6A-J4A1/
FC6A-J4A4
55°C 4 analog inputs -
65°C 4 analog inputs -
FC6A-J8A1/
FC6A-J8A4
55°C 8 analog inputs -
65°C 8 analog inputs -
FC6A-L03CN1/
FC6A-L03CN4
55°C 2 analog inputs 1 analog output, Class 2
65°C 2 analog inputs 1 analog voltage output only, Class 2
FC6A-J4CN1/
FC6A-J4CN4
55°C 4 analog inputs -
65°C 4 analog inputs -
FC6A-K2A1/
FC6A-K2A4
55°C - 2 analog outputs, Class 2
65°C - 2 analog outputs, Class 2
FC6A-J8CU1/
FC6A-J8CU4
55°C 8 analog inputs -
65°C 8 analog inputs -
FC6A-J4CH1Y/
FC6A-J4CH4Y
55°C 4 analog inputs -
65°C 4 analog inputs -
Model Names Type
Air Temp
Inputs Outputs
