FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 2-193
2: P RODUCT S PECIFICATIONS
FC6B series
FC6B-D32K3C
55°C
16 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Ma x. 62.4 mA
16 transistor sink outputs:
24V DC, 0.1 A/PT resistive
Total Max. 1.28 A, Limited energy
65°C
16 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Ma x. 21 mA, 3 PTs
16 transistor sink outputs:
24V DC, 0.1 A/PT resistive
Total Max. 0.4 A, 4 PTs, Limited energy
FC6B-D32K4C
55°C
16 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Ma x. 62.4 mA
16 transistor sink outputs:
24V DC, 0.1 A/PT resistive
Total Max. 1.28 A, Limited energy
65°C
16 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Ma x. 21 mA, 3 PTs
16 transistor sink outputs:
24V DC, 0.1 A/PT resistive
Total Max. 0.4 A, 4 PTs, Limited energy
FC6B-D32P3C
55°C
16 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Ma x. 62.4 mA
16 transistor source outputs:
24V DC, 0.1 A/PT resistive
Total Max. 1.28 A, Limited energy
65°C
16 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Ma x. 21 mA, 3 PTs
16 transistor source outputs:
24V DC, 0.1 A/PT resistive
Total Max. 0.4 A, 4 PTs, Limited energy
FC6B-D32P4C
55°C
16 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Ma x. 62.4 mA
16 transistor source outputs:
24V DC, 0.1 A/PT resistive
Total Max. 1.28 A, Limited energy
65°C
16 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Ma x. 21 mA, 3 PTs
16 transistor source outputs:
24V DC, 0.1 A/PT resistive
Total Max. 0.4 A, 4 PTs, Limited energy
FC6B-C16R1A
55°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
7 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
65°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Ma x. 28 mA, 4 PTs
7 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
Total Max. 6 A, 3 PTs
FC6B-C16R1C
55°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
7 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
65°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Ma x. 28 mA, 4 PTs
7 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
Total Max. 6 A, 3 PTs
FC6B-C16P1C
55°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
7 transistor source outputs:
24V DC, 0.5 A/PT
Class 2
65°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Ma x. 17 mA, 3 PTs
7 transistor source outputs:
24V DC, 0.5 A/PT
Class 2
Total Max. 1 A, 2 PTs
FC6B-C16K1C
55°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
7 transistor sink outputs:
24V DC, 0.5 A/PT
Class 2
65°C
9 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Ma x. 17 mA, 3 PTs
7 transistor sink outputs:
24V DC, 0.5 A/PT
Class 2
Total Max. 1 A, 2 PTs
FC6B-C24R1A
55°C
14 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
10 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
65°C
14 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Ma x. 45 mA, 7 PTs
10 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
Total Max. 10 A, 5 PTs
Model Names Type Air Temp Inputs Outputs
