IDEC MICROSmart FC6A Series User Manual

2: P RODUCT S PECIFICATIONS
2-194 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
FC6B series
FC6B-C24R1C
55°C
14 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
10 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
65°C
14 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Tota l Max. 45 mA, 7 PTs
10 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
Total Max. 10 A, 5 PTs
FC6B-C24P1C
55°C
14 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
10 transistor source outputs:
24V DC, 0.5 A/PT
Class 2
65°C
14 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Tota l Max. 27 mA, 5 PTs
10 transistor source outputs:
24V DC, 0.5 A/PT
Class 2
Total Max. 2 A, 4 PTs
FC6B-C24K1C
55°C
14 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
10 transistor sink outputs:
24V DC, 0.5 A/PT
Class 2
65°C
14 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Tota l Max. 27 mA, 5 PTs
10 transistor sink outputs:
24V DC, 0.5 A/PT
Class 2
Total Max. 2 A, 4 PTs
FC6B-C40R1A
55°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
16 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
65°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Max. 80 mA, 12 PTs
16 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
Total Max. 16 A, 8 PTs
FC6B-C40R1C
55°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
16 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
65°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Total Max. 80 mA, 12 PTs
16 relay outputs:
240V AC / 30V DC, 2 A (GEN/RES) 7 A (Common)
Total Max. 16 A, 8 PTs
FC6B-C40P1C
55°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
16 transistor source outputs:
24V DC, 0.5 A/PT
Class 2
65°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Tota l Max. 48 mA, 8 PTs
16 transistor source outputs:
24V DC, 0.5 A/PT
Class 2
Total Max. 3 A, 6 PTs
FC6B-C40K1C
55°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
16 transistor sink outputs:
24V DC, 0.5 A/PT
Class 2
65°C
24 inputs: 24V DC,
Input 0, 1, 6, 7: 5 mA/PT
Others: 7 mA/PT
Tota l Max. 48 mA, 8 PTs
16 transistor sink outputs:
24V DC, 0.5 A/PT
Class 2
Total Max. 3 A, 6 PTs
Model Names Type Air Temp Inputs Outputs
