FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 2-195
2: P RODUCT S PECIFICATIONS
The following products can be used at Max Surrounding Air Temperature of 55°C only.
The input/output ratings of the following products at Max Surrounding Air Temperature of 55°C are as follows.
Model Names Type Air Temp Inputs Outputs
Analog I/O
module
FC6A-K4A1/
FC6A-K4A4
55°C - 4 analog outputs, Class 2
FC6A-L06A1/
FC6A-L06A4
55°C - 2 analog outputs, Class 2
FC6A-F2M1/
FC6A-F2M4
55°C 2 analog inputs 2 analog outputs or digital output, Class 2
FC6A-F2MR1/
FC6A-F2MR4
55°C 2 analog inputs
2 relay outputs:
250V AC/30V DC, 5 A (RES), 3 A (GEN)
HMI module FC6A-PH1 55°C - -
Cartridge base
module
FC6A-HPH1 55°C - -
Analog I/O
cartridge
FC6A-PJ2A 55°C 2 analog inputs -
FC6A-PJ2CP 55°C 2 analog inputs -
FC6A-PK2AV 55°C - 2 analog outputs
FC6A-PK2AW 55°C - 2 analog outputs
Communication
cartridge
FC6A-PC1 55°C - -
FC6A-PC3 55°C - -
FC6A-PC4 55°C - -
Digital I/O
cartridge
FC6A-PTK4 55°C -
4 transistor source outputs:
24V DC, 0.1 A/PT resistive
12V DC, 0.1 A/PT resistive
Limited energy
FC6A-PTS4 55°C -
4 transistor source outputs:
24V DC, 0.1 A/PT resistive
12V DC, 0.1 A/PT resistive
Limited energy
FC6A-PN4 55°C
4 inputs:
24V DC, 5 mA/PT
12V DC, 2.5 mA/PT
-
