IDEC MICROSmart FC6A Series User Manual

FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 3-39
3: I NSTALLATION AND W IRING
Internal Power Supply Current of the Modules and Cartridges
The CPU module cannot detect the internal power supply current that the expansion modules are using. Observe the
restrictions in this section because malfunction or failure may result if the FC6A Series MICROSmart is continuously used
when the current exceeds the limit.
Caution
Module Type Model
Internal 3.3 V
Line Current
*1
Internal 5 V
Line Current
Internal 24 V
Line Current
Digital I/O module
Digital input module
FC6A-N08B1/FC6A-N08B4 ― 30 mA ―
FC6A-N16B1/FC6A-N16B4 ― 40 mA ―
FC6A-N16B3 ― 40 mA ―
FC6A-N32B3 ― 65 mA ―
FC6A-N08A11/FC6A-N08A14 ― 40 mA ―
Digital output module
FC6A-R081/FC6A-R084 ― 35 mA 6 mA/point
FC6A-R161/FC6A-R164 ― 50 mA 6 mA/point
FC6A-T08P1/FC6A-T08P4 ― 25 mA 1.5 mA/point
FC6A-T16P1/FC6A-T16P4 ― 30 mA 1.5 mA/point
FC6A-T16P3 ― 30 mA 1.5 mA/point
FC6A-T32P3 ― 45 mA 1.5 mA/point
FC6A-T08K1/FC6A-T08K4 ― 25 mA 1.5 mA/point
FC6A-T16K1/FC6A-T16K4 ― 30 mA 1.5 mA/point
FC6A-T16K3 ― 30 mA 1.5 mA/point
FC6A-T32K3 ― 45 mA 1.5 mA/point
Digital mixed I/O module
FC6A-M08BR1/FC6A-M08BR4 ― 30 mA 6 mA/point
FC6A-M24BR1/FC6A-M24BR4 ― 55 mA 6 mA/point
Analog I/O module
Analog input module
FC6A-J2C1/FC6A-J2C4 ― 40 mA ―
FC6A-J4A1/FC6A-J4A4 ― 45 mA ―
FC6A-J8A1/FC6A-J8A4 ― 40 mA ―
FC6A-J4CN1/FC6A-J4CN4 ― 50 mA ―
FC6A-J4CH1Y/FC6A-J4CH4Y ― 50 mA ―
FC6A-J8CU1/FC6A-J8CU4 ― 45 mA ―
Analog output module
FC6A-K2A1/FC6A-K2A4 ― 40 mA ―
FC6A-K4A1/FC6A-K4A4 ― 50 mA ―
Analog mixed I/O module
FC6A-L03CN1/FC6A-L03CN4 ― 55 mA ―
FC6A-L06A1/FC6A-L06A4 ― 60 mA ―
PID module
FC6A-F2M1/FC6A-F2M4 ― 65 mA ―
FC6A-F2MR1/FC6A-F2MR4 ― 65 mA ―
Serial communication module FC6A-SIF52/FC6A-SIF524 ― 35 mA 35 mA
Cartridges
Digital I/O cartridge
FC6A-PN4 35mA ――
FC6A-PTK4 35mA ――
FC6A-PTS4 35mA ――
Analog I/O cartridge
FC6A-PJ2A 35mA ――
FC6A-PJ2CP 35mA ――
FC6A-PK2AV 35mA 80 mA ―
FC6A-PK2AW 35mA 190 mA ―
Communication cartridge
FC6A-PC1 35mA 10 mA ―
FC6A-PC3 35mA 60 mA ―
FC6A-PC4 35mA 120 mA ―
Cartridge base module (no installed cartridges)
*2
FC6A-HPH1 ―――
HMI module (no installed cartridges) FC6A-PH1 ― 150 mA 15 mA
*3
