FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 5-17
5: F UNCTIONS AND S ETTINGS
Plus CPU module
External inputs I0/I1 (Group 1-2), external inputs I3/I4 (Group 3-4), and external inputs I6/I7 (Group 5-6) can be used as two-
phase high-speed counters.
External inputs I2, I13 (Plus 32-I/O type only), and I5 can be used as reset inputs for Group 1-2, Group 3-4, and Group 5-6
respectively.
*1 Can be used only with the Plus 32-I/O type.
*2 If I2, I13 (Plus 32-I/O type only), or I5 is not used as reset inputs (Z-phase), they can be used as normal inputs.
Group 123 456
External Input I2 I0 I1 I13
*1
I3 I4 I5 I6 I7
Two-phase
High-speed
Counter
Reset input
(Z-phase)
*2
Pulse input
(A-phase)
Pulse input
(B-phase)
Reset input
(Z-phase)
*2
Pulse input
(A-phase)
Pulse input
(B-phase)
Reset input
(Z-phase)
*2
Pulse input
(A-phase)
Pulse input
(B-phase)
