IDEC MICROSmart FC6A Series User Manual

6: D EVICES
6-2 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Plus CPU module
*1 The least significant digit of the device address is an octal number (0 to 7).
*2 I1310 to I627 and Q310 to Q627 are devices that can only be used when expansion modules are connected at the expansion interface side
using the expansion interface module (expander). (Node 0)
*3 I630 to I643 and Q630 to Q643 are devices that can be used only when I/O cartridges are connected.
*4 I1000 to I10597 and Q1000 to Q10597 are devices that can be used only when expansion modules are connected using the expansion interface
modules (remote master and slaves) and the expansion interface modules (expander). (Node 1 to 10)
*5 D70000 to D269999 cannot be designated as "Keep." Data register values are kept when you switch the PLC from Stop to Run, but those values
are cleared at power up.
*6 The data type that can be used is L (Long) only.
*7 Usable only in scripts executed by the SCRPT instruction and as argument devices used in UMACRO instructions.
Device Symbol Unit
Range (Points)
Plus 16-I/O Type Plus 32-I/O Type
Inputs
*1
IBit
I0 - I7
(8 points)
I0 - I17
(16 points)
Expansion Inputs
*1
IBit
I30 - I307
(224 points)
I310 - I627
*2
(256 points)
I630 - I643
*3
(12 points)
I1000 - I10597
*4
(2,016 points)
Output
*1
QBit
Q0 - Q7
(8 points)
Q0 - Q17
(16 points)
Expansion Outputs
*1
QBit
Q30 - Q307
(224 points)
Q310 - Q627
*2
(256 points)
Q630 - Q643
*3
(12 points)
Q1000 - Q10597
*4
(2,016 points)
Internal Relay
*1
MBit
M0 - M7997
(6,400 points)
M10000 - M21247
(9,000 points)
Special Internal Relay
*1
MBit
M8000 - M9997
(1,600 points)
Shift Register R Bit
R0 - R255
(256 points)
Timer T Bit/Word
T0 - T1999
(2,000 points)
Counter C Bit/Word
C0 - C511
(512 points)
Data Register D Bit/Word
D0000 - D7999
(8,000 points)
D10000 - D61999
(52,000 points)
Non-retentive Data
Register
DBit
*7
/Word
D70000 - D269999
*5
(200,000 points)
Special Data Register D Bit/Word
D8000 - D8899
(900 points)
Index Register
*6
P2 words
P0 - P15
(16 points)
