FC6A S

ERIES

MICROS

MART

SER

’

ANUAL

FC9Y-B1722 6-5

6: D

EVICES

M8051

High-speed Counter (Group 2/I1)

Comparison Output Reset Cleared Cleared R/W

M8052 Gate Input Maintained Cleared R/W

M8053 Reset Input Maintained Cleared R/W

M8054 Comparison ON Status Maintained Cleared R

M8055 Overflow Maintained Cleared R

M8056 — Reserved — — — —

M8057

High-speed Counter (Group 6/I7)

Comparison Output Reset Cleared Cleared R/W

M8060 Gate Input Maintained Cleared R/W

M8061 Reset Input Maintained Cleared R/W

M8062 Comparison ON Status Maintained Cleared R

M8063 Overflow Maintained Cleared R

M8064 to

M8067

— Reserved — — — —

M8070 SD Memory Card Mount Status Maintained Cleared R

M8071 Accessing SD Memory Card Maintained Cleared R

M8072 Unmount SD Memory Card Operating Cleared R/W

M8073 Function Switch Status Operating Cleared R

M8074 Battery Voltage Measurement Flag Operating Cleared R/W

M8075 to

M8077

— Reserved — — — —

M8080 Data Link Slave 1 Communication Completed Relay (When Data Link Master) Operating Cleared R

M8081 Data Link Slave 2 Communication Completed Relay Operating Cleared R

M8082 Data Link Slave 3 Communication Completed Relay Operating Cleared R

M8083 Data Link Slave 4 Communication Completed Relay Operating Cleared R

M8084 Data Link Slave 5 Communication Completed Relay Operating Cleared R

M8085 Data Link Slave 6 Communication Completed Relay Operating Cleared R

M8086 Data Link Slave 7 Communication Completed Relay Operating Cleared R

M8087 Data Link Slave 8 Communication Completed Relay Operating Cleared R

M8090 Data Link Slave 9 Communication Completed Relay Operating Cleared R

M8091 Data Link Slave 10 Communication Completed Relay Operating Cleared R

M8092 Data Link Slave 11 Communication Completed Relay Operating Cleared R

M8093 Data Link Slave 12 Communication Completed Relay Operating Cleared R

M8094 Data Link Slave 13 Communication Completed Relay Operating Cleared R

M8095 Data Link Slave 14 Communication Completed Relay Operating Cleared R

M8096 Data Link Slave 15 Communication Completed Relay Operating Cleared R

M8097 Data Link Slave 16 Communication Completed Relay Operating Cleared R

M8100 Data Link Slave 17 Communication Completed Relay Operating Cleared R

M8101 Data Link Slave 18 Communication Completed Relay Operating Cleared R

M8102 Data Link Slave 19 Communication Completed Relay Operating Cleared R

M8103 Data Link Slave 20 Communication Completed Relay Operating Cleared R

M8104 Data Link Slave 21 Communication Completed Relay Operating Cleared R

M8105 Data Link Slave 22 Communication Completed Relay Operating Cleared R

M8106 Data Link Slave 23 Communication Completed Relay Operating Cleared R

M8107 Data Link Slave 24 Communication Completed Relay Operating Cleared R

M8110 Data Link Slave 25 Communication Completed Relay Operating Cleared R

M8111 Data Link Slave 26 Communication Completed Relay Operating Cleared R

M8112 Data Link Slave 27 Communication Completed Relay Operating Cleared R

M8113 Data Link Slave 28 Communication Completed Relay Operating Cleared R

M8114 Data Link Slave 29 Communication Completed Relay Operating Cleared R

M8115 Data Link Slave 30 Communication Completed Relay Operating Cleared R

M8116 Data Link Slave 31 Communication Completed Relay Operating Cleared R

M8117 Data Link All Slaves Communication Completed Relay Operating Cleared R

M8120 Initialize Pulse Cleared Cleared R

M8121 1-s Clock Operating Cleared R

M8122 100-ms Clock Operating Cleared R

Device

Address

Description

When

Stopped

Power

OFF

R/W
