6: D

EVICES

6-6 FC6A S

ERIES

MICROS

MART

SER

’

ANUAL

FC9Y-B1722

M8123 10-ms Clock Operating Cleared R

M8124 Timer/Counter Preset Value Changed Maintained Cleared R

M8125 In-operation Output Cleared Cleared R

M8126 1 Scan ON After Run-Time Download Completes Cleared Cleared R

M8127 — Reserved — — — —

M8130

High-speed Counter (Group 1/I0)

Reset Status Maintained Cleared R

M8131 Comparison ON Status Maintained Cleared R

M8132 — Reserved — — — —

M8133 High-speed Counter (Group 3/I3) Comparison ON Status Maintained Cleared R

M8134 High-speed Counter (Group 4/I4) Comparison ON Status Maintained Cleared R

M8135

High-speed Counter (Group 5/I6)

Reset Status Maintained Cleared R

M8136 Comparison ON Status Maintained Cleared R

M8137 Interrupt Input I0 Status (Group 1/I0)

(ON: Allowed, OFF: Prohibited)

Cleared Cleared R

M8140 Interrupt Input I1 Status (Group 2/I1) Cleared Cleared R

M8141 Interrupt Input I3 Status (Group 3/I3) Cleared Cleared R

M8142 Interrupt Input I4 Status (Group 4/I4) Cleared Cleared R

M8143 Interrupt Input I6 Status (Group 5/I6) Cleared Cleared R

M8144 Timer Interrupt Status Cleared Cleared R

M8145 User Communication Receive Instruction Cancel Flag (Port 5) Cleared Cleared R/W

M8146 User Communication Receive Instruction Cancel Flag (Port 6) Cleared Cleared R/W

M8147 User Communication Receive Instruction Cancel Flag (Port 7) Cleared Cleared R/W

M8150 Comparison Result 1 Maintained Cleared R

M8151 Comparison Result 2 Maintained Cleared R

M8152 Comparison Result 3 Maintained Cleared R

M8153

Catch Input ON/OFF Status

Group 1/I0 Maintained Cleared R

M8154 Group 2/I1 Maintained Cleared R

M8155 Group 3/I3 Maintained Cleared R

M8156 Group 4/I4 Maintained Cleared R

M8157 Group 5/I6 Maintained Cleared R

M8160 Group 6/I7 Maintained Cleared R

M8161

High-speed Counter (Group 1/I0)

Overflow Maintained Cleared R

M8162 Underflow Maintained Cleared R

M8163

High-speed Counter (Group 5/I6)

Overflow Maintained Cleared R

M8164 Underflow Maintained Cleared R

M8165 High-speed Counter (Group 3/I3) Overflow Maintained Cleared R

M8166 High-speed Counter (Group 4/I4) Overflow Maintained Cleared R

M8167 Interrupt Input I7 Status (Group 6/I7) (ON: Allowed, OFF: Prohibited) Maintained Cleread R

M8170 User Communication Receive Instruction Cancel Flag (Port 8) Cleared Cleared R/W

M8171 — Reserved — — — —

M8172

Transistor Source Output Overcurrent

Detection

Group 1 Operating Cleared R

M8173 Group 2 Operating Cleared R

M8174 Group 3 Operating Cleared R

M8175 Group 4 Operating Cleared R

M8176 User Communication Receive Instruction Cancel Flag (Port 9) Cleared Cleared R/W

M8177 to

M8183

— Reserved — — — —

M8184 Change HMI Module Network Settings Trigger Operating Cleared R/W

M8185 In Daylight Saving Time Period Operating Cleared R

M8186 Ethernet Port 1 Executing Auto Ping Operating Cleared R

M8187 Ethernet Port 1 Auto Ping Stop Flag Operating Cleared R/W

M8190 Change CPU Module Ethernet Port 1 Network Settings Trigger Operating Cleared R/W

M8191 SNTP Acquisition Flag Operating Cleared R/W

Device

Address

Description

When

Stopped

Power

OFF

R/W
