FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 6-29
6: D EVICES
Supplementary Descriptions of the Special Data Registers
■ D8000: Quantity of Inputs
The number of FC6A Series MICROSmart inputs is written to this register.
The total number of inputs for the CPU module and the expansion modules is written to this register.
■ D8001: Quantity of Outputs
The number of FC6A Series MICROSmart outputs is written to this register.
The total number of outputs for the CPU module and the expansion modules is written to this register.
■ D8002: CPU Module Type Information
CPU module type information is written this register.
0 (00h): 16-I/O type
1 (01h): 24-I/O type
2 (02h): 40-I/O type (All-in-One CPU module)
18 (12h): 40-I/O type (CAN J1939 All-in-One CPU module)
32 (20h): Plus 16-I/O type
33 (21h): Plus 32-I/O type
■ D8005: General Error Code
FC6A Series MICROSmart general error information is written to this register. When a general error occurs, the bit corresponding
to the error occurred turns on. The general error and user program execution error can be cleared by writing "1" to the most
significant bit of D8005. For details on general error codes, see "General Error Codes" on page 13-3.
D8746 Slave Number (Port 21) ― R/W
D8747 Slave Number (Port 22) ― R/W
D8748 Slave Number (Port 23) ― R/W
D8749 Slave Number (Port 24) ― R/W
D8750 Slave Number (Port 25) ― R/W
D8751 Slave Number (Port 26) ― R/W
D8752 Slave Number (Port 27) ― R/W
D8753 Slave Number (Port 28) ― R/W
D8754 Slave Number (Port 29) ― R/W
D8755 Slave Number (Port 30) ― R/W
D8756 Slave Number (Port 31) ― R/W
D8757 Slave Number (Port 32) ― R/W
D8758 Slave Number (Port 33) ― R/W
D8759 EMAIL Instruction Detailed Error Information (Ethernet Port 1) ― R
D8760
Communication Mode Information
(Client Connection)
Connection 9 to 12 ― R
D8761 Connection 13 to 16 ― R
D8762 to
D8773
— Reserved — ――
D8774 Remote Host Number of Connection 9 (1 to 255) ― R/W
D8775 Remote Host Number of Connection 10 (1 to 255) ― R/W
D8776 Remote Host Number of Connection 11 (1 to 255) ― R/W
D8777 Remote Host Number of Connection 12 (1 to 255) ― R/W
D8778 Remote Host Number of Connection 13 (1 to 255) ― R/W
D8779 Remote Host Number of Connection 14 (1 to 255) ― R/W
D8780 Remote Host Number of Connection 15 (1 to 255) ― R/W
D8781 Remote Host Number of Connection 16 (1 to 255) ― R/W
D8782 BACnet Operation Status ― R
D8783 BACnet Error Information ― R
D8784 to
D8789
— Reserved — ――
D8790 EtherNet/IP Operation Status ― R
D8791 EtherNet/IP Error Information ― R
D8792 to
D8899
— Reserved — ――
Device
Address
Description Update Timing R/W
