6: D EVICES
6-46 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
The system software version displays the version of the software written to the device.
For details on the type IDs and statuses, see "List of Type IDs and Status" on page 6-49.
■ D8596, D8597: Expansion Interface Remote Master Module Slot Information
Expansion interface remote master module type information is written to these registers.
The allocation of information (bit assignment) is as follows.
The system software version displays the version of the software written to the device.
For details on the type IDs and statuses, see "List of Type IDs and Status" on page 6-49.
■ D8598 to D8617: Expansion Interface Remote Slave Module Slot Information
Expansion interface remote slave module type information is written to these registers.
The allocation of information (bit assignment) is as follows.
The system software version displays the version of the software written to the device.
For details on the type ID and status, see "List of Type IDs and Status" on page 6-49.
■ D8618: Refresh Time of Expansion Interface Remote Master/Slave Modules Current Value
The current value of the I/O refresh time of the expansion modules connected with the expansion interface remote master/slave
modules is stored in increments of 1 ms.
■ D8619: Refresh Time of Expansion Interface Remote Master/Slave Modules Maximum Value
The maximum value of the I/O refresh time of the expansion modules connected with the expansion interface remote master/
slave modules is stored in increments of 1 ms.
D8590, D8591 = Expansion Module Slot 61 Information
D8592, D8593 = Expansion Module Slot 62 Information
D8594, D8595 = Expansion Module Slot 63 Information
Upper Lower
D8598, D8599 = Expansion Interface Remote Slave Module (Unit 1) Slot Information
D8600, D8601 = Expansion Interface Remote Slave Module (Unit 2) Slot Information
D8602, D8603 = Expansion Interface Remote Slave Module (Unit 3) Slot Information
D8604, D8605 = Expansion Interface Remote Slave Module (Unit 4) Slot Information
D8606, D8607 = Expansion Interface Remote Slave Module (Unit 5) Slot Information
D8608, D8609 = Expansion Interface Remote Slave Module (Unit 6) Slot Information
D8610, D8611 = Expansion Interface Remote Slave Module (Unit 7) Slot Information
D8612, D8613 = Expansion Interface Remote Slave Module (Unit 8) Slot Information
D8614, D8615 = Expansion Interface Remote Slave Module (Unit 9) Slot Information
D8616, D8617 = Expansion Interface Remote Slave Module (Unit 10) Slot Information
Upper Lower
Status
Type ID
Upper
Number of Connected Expansion Interface
Remote Slave Modules
System Software Version
Lower
Bit
15
Bit
0
Bit
7
Bit
8
12 34 5 6 910 1112 13 14
Status
Type ID
Upper
Expansion Module Connection Information
System Software Version
Lower
Reserved Number of Connected
Expansion Modules
(0 to 15)
Bit
15
Bit
0
Bit
7
Bit
8
12 34 5 6 910 1112 13 14
