FC6A S
ERIES
MICROS
MART
U
SER
’
S
M
ANUAL
FC9Y-B1722 6-47
6: D
EVICES
■ D8630: CPU Module Ethernet Port 2 IP Settings/DNS Settings Switching
The IP settings/DNS settings for Ethernet Port 2 can be changed by writing one of the setting values in the following table to
D8630 and then turning on M8333.
To use this function, enable Enable D8630 (IP Settings / DNS Settings switching) on Ethernet Port 2 in Function Area
Settings of WindLDR.
The meanings of the setting values are as follows.
■ D8631 to D8634: CPU Module Ethernet Port 2 IP Address (Write-only)
These registers are used to write the IP address of Ethernet port 2 on the Plus CPU module.
IP address: To set as aaa.bbb.ccc.ddd, write the following.
D8631 = aaa, D8632 = bbb, D8633 = ccc, D8634 = ddd
■ D8635 to D8638: CPU Module Ethernet Port 2 Subnet Mask (Write-only)
These registers are used to write the subnet mask of Ethernet port 2 on the Plus CPU module.
Subnet mask: For aaa.bbb.ccc.ddd, write the following.
D8635 = aaa, D8636 = bbb, D8637 = ccc, D8638 = ddd
■ D8639 to D8642: CPU Module Ethernet Port 2 Default Gateway (Write-only)
These registers are used to write the default gateway of Ethernet port 2 on the Plus CPU module.
Default gateway: For aaa.bbb.ccc.ddd, write the following.
D8639 = aaa, D8640 = bbb, D8641 = ccc, D8642 = ddd
■ D8643 to D8646: CPU Module Ethernet Port 2 Preferred DNS Server (Write-only)
These registers are used to write the preferred DNS server of Ethernet port 2 on the Plus CPU module.
Preferred DNS server: For aaa.bbb.ccc.ddd, write the following.
D8643 = aaa, D8644 = bbb, D8645 = ccc, D8646 = ddd
■ D8647 to D8650: CPU Module Ethernet Port 2 Alternate DNS Server (Write-only)
These registers are used to write the alternate DNS server of Ethernet port 2 on the Plus CPU module.
Alternate DNS server: For aaa.bbb.ccc.ddd, write the following.
D8647 = aaa, D8648 = bbb, D8649 = ccc, D8650 = ddd
■ D8651 to D8656: CPU Module Ethernet Port 2 MAC Address (Current Value Read-only)
The MAC address of Ethernet port 2 on the Plus CPU module is written to the special data registers as follows.
Example: MAC address: AA-BB-CC-DD-EE-FF
D8651 = AA, D8652 = BB, D8653 = CC, D8654 = DD, D8655 = EE, D8656 = FF
■ D8657 to D8660: CPU Module Ethernet Port 2 IP Address (Current Value Read-only)
The IP address of Ethernet port 2 on the Plus CPU module is written to the special data registers as follows.
Example: The CPU module's own IP address: aaa.bbb.ccc.ddd
D8657 = aaa, D8658 = bbb, D8659 = ccc, D8660 = ddd
■ D8661 to D8664: CPU Module Ethernet Port 2 Subnet Mask (Current Value Read-only)
The subnet mask value of Ethernet port 2 on the Plus CPU module is written to the special data registers as follows.
Example: Subnet mask: aaa.bbb.ccc.ddd
D8661 = aaa, D8662 = bbb, D8663 = ccc, D8664 = ddd
■ D8665 to D8668: CPU Module Ethernet Port 2 Default Gateway (Current Value Read-only)
The default gateway address of Ethernet port 2 on the Plus CPU module is written to the special data registers as follows.
Example: Default gateway: aaa.bbb.ccc.ddd
D8665 = aaa, D8666 = bbb, D8667 = ccc, D8668 = ddd
Setting Value IP Settings/DNS Settings
0 Conform to function area settings.
1Enable DHCP.
2 Conform to special data register (D8631 to D8650) settings.
