IDEC MICROSmart FC6A Series User Manual

7: HMI F UNCTION
7-28 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Changing the Message Display Settings
Modifying the Scroll Speed
The scroll speed for messages displayed with the message (MSG) instruction can be configured.
These settings can be configured when the user program is stopped. This cannot be configured while the user program is running.
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select Configurations with the (up) and (down) buttons and press the (OK) button.
3. Select Function with the (up) and (down) buttons and press the (OK) button.
4. Select Message Settings with the (up) and (down) buttons and press the (OK) button.
5. Select Scroll Settings with the (up) and (down) buttons and press the (OK) button.
6. Select Scroll Speed with the (up) and (down) buttons and press the (OK) button.
7. Modify the value with the (up) and (down) buttons and press the (OK) button.
For example, change the value to 700 ms.
 Selectable scroll speeds
The scroll speeds that can be selected are as follows.
500/600/700/800/900/1000 ms
Stopped
2015/DEC/01/TUE
13:30:40
Run
Edit Program
External Memory
Configurations
Function
Clock
Menu Languages
Backlight
Communications
Message Settings
Scroll Settings
Blink Settings
Scroll Speed:
500 ms
Scroll Unit:
1-character
Scroll Speed:
700 ms
Scroll Unit:
1-character
