FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 7-29
7: HMI F UNCTION
Configuring the Scroll Unit
The scroll unit for messages displayed with the message (MSG) instruction can be configured.
These settings can be configured when the user program is stopped. This cannot be configured while the user program is running.
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select Configurations with the (up) and (down) buttons and press the (OK) button.
3. Select Function with the (up) and (down) buttons and press the (OK) button.
4. Select Message Settings with the (up) and (down) buttons and press the (OK) button.
5. Select Scroll Settings with the (up) and (down) buttons and press the (OK) button.
6. Select Scroll Unit with the (up) and (down) buttons and press the (OK) button.
7. Modify the scroll unit with the (up) and (down) buttons and press the (OK) button.
 Selectable scroll units
The scroll units that can be selected are as follows.
1 character/1-dot
Stopped
2015/DEC/01/TUE
13:30:40
Run
Edit Program
External Memory
Configurations
Function
Clock
Menu Languages
Backlight
Communications
Message Settings
Scroll Settings
Blink Settings
Scroll Speed:
500 ms
Scroll Unit:
1-character
Scroll Unit:
1-dot
