IDEC MICROSmart FC6A Series User Manual

9: A NALOG I/O M ODULES
9-16 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Input
CH3
Signal type R/W ― +23+31+23+23+40
Data type R/W ― +24+32+24+24+41
Minimum value R/W ― +25+33+25+25+42
Maximum value R/W ― +26+34+26+26+43
Filter value R/W ― +27+35+27+27+44
Thermistor constant (R0) R/W ―――――+45
Thermistor constant (T0) R/W ―――――+46
Thermistor constant (B) R/W ―――――+47
CH4
Signal type R/W ――+36 ――+48
Data type R/W ――+37 ――+49
Minimum value R/W ――+38 ――+50
Maximum value R/W ――+39 ――+51
Filter Value R/W ――+40 ――+52
Thermistor constant (R0) R/W ―――――+53
Thermistor constant (T0) R/W ―――――+54
Thermistor constant (B) R/W ―――――+55
CH5
Signal type R/W ――+41 ――+56
Data type R/W ――+42 ――+57
Minimum value R/W ――+43 ――+58
Maximum value R/W ――+44 ――+59
Filter value R/W ――+45 ――+60
Thermistor constant (R0) R/W ―――――+61
Thermistor constant (T0) R/W ―――――+62
Thermistor constant (B) R/W ―――――+63
CH6
Signal type R/W ――+46 ――+64
Data type R/W ――+47 ――+65
Minimum value R/W ――+48 ――+66
Maximum value R/W ――+49 ――+67
Filter Value R/W ――+50 ――+68
Thermistor constant (R0) R/W ―――――+69
Thermistor constant (T0) R/W ―――――+70
Thermistor constant (B) R/W ―――――+71
CH7
Signal type R/W ――+51 ――+72
Data type R/W ――+52 ――+73
Minimum value R/W ――+53 ――+74
Maximum value R/W ――+54 ――+75
Filter value R/W ――+55 ――+76
Thermistor constant (R0) R/W ―――――+77
Thermistor constant (T0) R/W ―――――+78
Thermistor constant (B) R/W ―――――+79
Channel
Parameter R/W
FC6A-J2C1
FC6A-J2C4
FC6A-J4A1
FC6A-J4A4
FC6A-J8A1
FC6A-J8A4
FC6A-J4CN1
FC6A-J4CN4
FC6A-J4CH1Y
FC6A-J4CH4Y
FC6A-J8CU1
FC6A-J8CU4
I/O No.
