IDEC MICROSmart FC6A Series User Manual

10: I/O C ARTRIDGES
10-10 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Analog I/O Assignments
The analog inputs or analog outputs are assigned as follows.
Notes:
 AI1 is an All-in-One CPU module analog input. For details, see "Analog Voltage Input" on page 5-44.
 AI0 is an All-in-One CPU module analog potentiometer. For details, see "Analog Potentiometer" on page 5-46.
Assignment Example
All-in-One
CPU
Module
CAN J1939
All-in-One
CPU
Module
Analog I/O Cartridge
Cartridge Slot 1 Cartridge Slot 2 Cartridge Slot 3
Channel ――IN0/OUT0 IN1/OUT1 IN0/OUT0 IN1/OUT1 IN0/OUT0 IN1/OUT1
Analog No.
(AI/AQ)
AI1 ― AI2/AQ2 AI3/AQ3 AI4/AQ4 AI5/AQ5 AI6/AQ6 AI7/AQ7
Example 1) The assignments for the 40-I/O type when an analog input cartridge is installed in cartridge slot 1, an analog
output cartridge is installed in cartridge slot 2, and an analog output cartridge is installed in cartridge slot 3 on
the HMI module
All-in-One
CPU
Module
Analog I/O Cartridge
40-I/O Type Cartridge Slot 1 Cartridge Slot 2 Cartridge Slot 3
Channel ― IN0 IN1 OUT0 OUT1 OUT0 OUT1
Analog input AI1 AI2 AI3 ――――
Analog output ―――AQ4 AQ5 AQ6 AQ7
Example 2) The assignments for the CAN J1939 All-in-One CPU module when an analog input cartridge is installed in
cartridge slot 1
CAN J1939
All-in-One
CPU
Module
Analog I/O Cartridge
Cartridge Slot 1 Cartridge Slot 2 Cartridge Slot 3
Channel ― IN0 IN1 ――――
Analog input ― AI2 AI3 ――――
Analog output ― ――――――
