11: SD M EMORY C ARD
11-6 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
ZLD Files
Downloads and uploads with the SD memory card use ZLD files that contain the user program, program comments, and system
software data in a single file.
ZLD files are created with WindLDR or by uploading to the SD memory card. Data can be reused and edited by opening the ZLD
file in WindLDR.
When creating a ZLD file with WindLDR, the data other than the user program can be optionally set. The version of the CPU
module system software can also be specified and set.
When downloading from the SD memory card, the data in the ZLD file cannot be partially selected and downloaded. To change the
data that will be download according to the application, create it as a separate ZLD file.
The data that is written to the ZLD file is as follows.
*1 If the applicable data is not set in the ZLD file, the corresponding data will not be downloaded.
The created ZLD file is saved to the \FCDATA01\PROGRAM\ folder on the SD memory card. ZLD files can be saved to folders other
than the \FCDATA01\PROGRAM\ folder, but these will not be downloaded from the SD memory card. Alpha-numeric characters, "-"
(hyphens), "_" (underscores), and spaces can be used for the file name.
autoexec.ini File
Using the autoexec.ini file, the file name and action can be changed when downloading or uploading a ZLD file when the FC6A
Series MICROSmart power is turned on and by special internal relay operations. The autoexec.ini file is created by using WindLDR
or a text editor. Only the autoexec.ini file saved to \FCDATA01\ on the SD memory card is valid.
For the autoexec.ini file format, see "autoexec.ini File Format" on page 11-36.
mqtt_basic_settings.ini File
The basic settings for performing MQTT communication, root certificate of the server certificate, client certificate, and client private
key can be downloaded to the CPU module by using an mqtt_basic_settings.ini file when the FC6A Series MICROSmart power is
turned on and by special internal relay operations. The mqtt_basic_settings.ini file is created by using WindLDR or a text editor.
Only the mqtt_basic_settings.ini file saved to \FCDATA01\ on the SD memory card is valid.
For the mqtt_basic_settings.ini file format, see "mqtt_basic_settings. ini File Format" on page 11-41.
Formatting the SD Memory Card
The SD memory card inserted in the FC6A Series MICROSmart CPU module can be formatted by operations with Data File Manager
and by menu operations on the HMI module.
For details, see "Formatting the SD Memory Card" on page 11-56 and "Format SD memory card with the FC6A Series
MICROSmart" on page 7-42.
ZLD File Data When Creating ZLD Files in WindLDR
When the CPU Module Creates ZLD Files by
Uploading Data to the SD Memory Card
User program Set from a created user program. The user program running on the CPU module is written.
Program comments
Set the user program comments.
(Optional)
*1
The program comments running on the CPU module are
written.
CPU module system
software
Specify and set the CPU module system software
version. (Optional)
*1
The system software running on the CPU module is
written.
