FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722 11-13
11: SD M EMORY C ARD
When the trigger devices are simultaneously turned on for multiple recipe blocks
Processing is executed in order from the lowest recipe block number. However, if a new trigger device is turned on for the recipe block
being executed, it will be executed as the new recipe block after reading or writing of the recipe block being executed has finished.
Used Special Devices
The special internal relays and the special data registers used by the recipe function are as follows.
Special Internal Relays
Special Data Registers
Scan
Block
Number
Trigger Device
Recipe Execution Status
Channel 1 Channel 8 Channel 15
1st scan
1 OFF OFF OFF
No operation
30 OFF OFF OFF
2nd scan
1 OFF -> ON OFF OFF -> ON
Execute channel 1 in block 1
30 OFF -> ON OFF OFF
3rd scan
1 ON OFF -> ON ON
Execute channel 15 in block 1
30 ON OFF OFF
4th scan
1ONONON
Execute channel 1 in block 30
30 ON OFF OFF
5th scan
1ONON ON
Execute channel 8 in block 1
30 ON OFF OFF
Device Address Function Description
M8260 Write Recipe Execution Flag When M8260 is turned on, write recipe is executed.
M8261 Read Recipe Execution Flag When M8261 is turned on, read recipe is executed.
M8262 Executing Write Recipe
M8262 is turned on when the write recipe processing starts, and it is turned off when the
processing has completed. M8262 also is turned off when read recipe processing starts.
M8263 Executing Read Recipe
M8263 is turned on when the read recipe processing starts, and it is turned off when the
processing has completed. M8263 also is turned off when write recipe processing starts.
M8264
Recipe Channel Execution
Completed Output
M8264 is turned off when starting to read or write a recipe channel, and it is turned on when
reading or writing a recipe channel has completed.
M8265
Recipe Execution Error
Output
M8265 is turned on when recipe execution has completed and D8264 (Recipe Execution Status)
is a value other than 0.
M8266
Recipe Block Execution
Completed Output
M8266 is turned off when starting to read or write a recipe block, and it is turned on when
reading or writing a recipe block has completed.
M8267
Read Restriction for
Recipe Internal Memory
(ROM-Range)
M8267 is turned on when reading or writing to a recipe block in internal memory (ROM-Range)
has completed. When M8267 is on, recipes cannot be read to internal memory (ROM-Range).
When M8267 is off, recipes can be read to internal memory (ROM-Range).
Device Address Function Description
D8260 Recipe Block Number
The recipe block number to read or write using special internal relays.
All channels for the specified block number are applicable.
D8261
Recipe Execution Block
Number
The recipe block number of the recipe that was executed.
This is updated when the recipe block starts, and the status is retained when completed.
D8262
Recipe Execution Channel
No.
The channel number of the recipe that was executed.
This is updated when the channel processing starts, and the status is retained when completed.
D8263
Recipe Execution
Operation
Information about the operation of the recipe that was executed. For details, see "Recipe
Execution Operation (D8263)" on page 11-14.
D8264 Recipe Execution Status
The status of the recipe that was executed. This is 0 when normally terminated. For details, see "Recipe
Execution Status (D8264) and Recipe Execution Error Information (D8265)" on page 11-14.
M8264 turns on when this device is updated. M8265 also turns on if this device is a value other than 0.
D8265
Recipe Execution Error
Information
Error information about the recipe that was executed. This device is updated at the same time as
D8264. For details, see "Recipe Execution Status (D8264) and Recipe Execution Error Information
(D8265)" on page 11-14.
D8266
Recipe Internal Memory
(ROM-Range 1) Read
Count
The number of times device values are read to internal memory (ROM-Range 1) as recipe data is
stored in this register in units of 100. An error occurs when the actual read count exceeds 50,000
times (value of D8266 > 500).
D8267
Recipe Internal Memory
(ROM-Range 2) Read
Count
The number of times device values are read to internal memory (ROM-Range 2) as recipe data is
stored in this register in units of 100. An error occurs when the actual read count exceeds 50,000
times (value of D8267 > 500).
