11: SD M EMORY C ARD
11-14 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Recipe Execution Operation (D8263)
Details about information on the write recipe or read recipe operation that was executed is written to special data register D8263
(Recipe Execution Operation) are as follows.
Recipe Execution Status (D8264) and Recipe Execution Error Information (D8265)
Details about the status code that is written to special data register D8264 (Recipe Execution Status) when write recipe or read
recipe is executed and details about the error information that is written to special data register D8265 (Recipe Execution Error
Information) are as follows.
*2 This occurs when a block number was accessed that has no settings in the special data registers and special internal relays.
*3 This occurs when file data cannot be normally written or read due to the data in the file becoming corrupted or a failure of a specific area of the
SD memory card.
*4 This occurs when recipe data cannot be normally written due to the data in the recipe data in internal memory (ROM-Range) becoming
corrupted or a failure of a specific area of internal memory (ROM-Range).
D8264
(Status Code)
Write Recipe (Recipe to PLC) Read Recipe (PLC to Recipe)
D8265
(Error Information)
0 Normal termination Normal termination 0 (fixed)
1 No SD memory card is inserted. No SD memory card is inserted. 0 (fixed)
2 ―
The SD memory card is write
protected.
0 (fixed)
3 Invalid SD memory card format. Invalid SD memory card format. 0 (fixed)
4 ―
The SD memory card is full and no
folders or files can be created.
The channel number where file
creation failed is written to the device.
5
The specified recipe block number is
invalid.
*2
The specified recipe block number is
invalid.
The invalid recipe block number that
was specified is written.
6
Failed to read the recipe file on the
SD memory card.
*3
Failed to read the recipe file on the
SD memory card.
*3
The channel number where the
recipe file read failed is written to the
device.
7
There is no recipe file on the SD
memory card.
―
The channel number where there is
no recipe file is written to the device.
10
There is no recipe data in internal
memory (ROM-Range).
―
The channel number where there is no
recipe data is written to the device.
11 ―
A read to internal memory (ROM-
Range) was executed while reading
to internal memory (ROM-Range)
was restricted (when M8267 is on).
The block number set with internal
memory (ROM-Range 1) or internal
memory (ROM-Range 2) for the
access target is written to the device.
12 ―
 The write limit to internal memory
(ROM-Range) was exceeded.
 The number of times device
values were read to internal
memory (ROM-Range 1) as recipe
data exceeded 50,000 times. Or
the number of times device values
were read to internal memory
(ROM-Range 2) exceeded 50,000
times.
0 (fixed)
13
Writing recipe data to internal memory
(ROM-Range) failed.
*4
― 0 (fixed)
Bit
15
Bit
0
Bit
7
Bit
8
Bit
4
Bit
12
Execution Trigger
1: Trigger Device
2: Special Device
3: Auto Execution
4: HMI Operation
Reserved
0 (fixed)
Write Method
1: Read Recipe
2: Write Recipe
Access to
1: SD Memory Card
2: Internal Memory
(ROM-User Program)
3: Internal Memory
(ROM-Range 1)
4: Internal Memory
(ROM-Range 2)
Bit
3
Bit
11
