11: SD M EMORY C ARD
11-46 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
■ D8255: SD Memory Card Download/Upload Execution Error Information
*1 Double-byte characters and the single-byte characters / : , ; * ? " < > | cannot be used in the file name.\
*2 When file data cannot be normally written or read due to the data in the file becoming corrupted or a failure of a specific area of the SD memory
card.
*3 Except when the password has been canceled using the HMI module.
Download files for MQTT Basic Settings
The special internal relays and the special data registers used to download the files for MQTT Basic Settings are as follows.
Note: R/W stands for read/write and allows reading and writing. R is read-only. W is write-only.
Special Internal Relay
Status Download Upload M8255
0 Normal termination Normal termination OFF
1 No SD memory card is inserted. No SD memory card is inserted. ON
2 ― The SD memory card is write protected. ON
3 Invalid SD memory card format. Invalid SD memory card format. ON
4 ―
The SD memory card is full and no folders or files can be
created.
ON
5 The ZLD file name specified by src_file is invalid.
*1
The ZLD file name specified by dst_file is invalid.
*1
OFF
6 Failed to read the ZLD file saved to the SD memory card.
*2
Failed to write the ZLD file to the SD memory card.
*2
OFF
7 No ZLD file on the SD memory card. ― ON
8 ―
A program syntax error occurred and the ZLD file could
not be created.
ON
9
 No autoexec.ini file.
 The autoexec.ini could not be read.
 No autoexec.ini file.
 The autoexec.ini could not be read.
ON
10 The program download is password protected
*3
. The program upload is password protected
*3
.ON
11 ―――
12
The ZLD file saved on the SD memory card has an invalid
file size.
― ON
13
The target model of the ZLD file saved on the SD memory
card is different.
― ON
14 Other download processing is being executed. ― ON
15
The download was not executed because the user
program written to the FC6A Series MICROSmart was the
same as the data in the ZLD file saved to the SD memory
card.
― OFF
16
The download was not executed because the system
software and user program written to the FC6A Series
MICROSmart was the same as the data in the ZLD file
saved to the SD memory card.
The download was not executed because the system
software and user program written to the FC6A Series
MICROSmart was the same as the data in the ZLD file
saved to the SD memory card.
OFF
Address Description R/W
M8271
Download MQTT Basic Settings from
SD Memory Card Execution Flag
When M8271 is turned on, the files for MQTT Basic Settings are downloaded. R/W
M8272
Download MQTT Basic Settings from
SD Memory Card Execution
Completion Output
M8272 is turned off when downloading the files for MQTT Basic Settings is
started, and it is turned on once the download is finished.
R
M8273
Download MQTT Basic Settings from
SD Memory Card Error Output
M8273 is turned off when downloading the files for MQTT Basic Settings is
started. It is turned on if an error occurs during the process.
R
