Downloading and Uploading Device Address Data
Device Address Data
Device Address Data Format
The device address data consists of group of values. The number of values is specified with Number of Data in Device Address
Data Setting dialog box.
Creating Device Address Data with Text Editor
The device address data can be created with software tool such as Notepad, text editor from the third party, or spread sheet
software.
1. Describe "Device Address Value", comma (,), and line feed as many as the number of data.
Example: When the number of data is 5 and values are 1111, 2222, 3333, 4444, 5555 in this order
1111,
2222,
3333,
4444,
5555,
2. Save the file with the extension (.csv).
Supported Device Address
The range of device addresses that can be read or written and the maximum number of data are as follows.
Device Name
FC6A-C16/-C24/-C40/-C40XEJ FC6A-D16/-D32
Device Address Max Number of Data Device Address Max Number of Data
Internal relay
M0 to M7997 6,400 M0 to M7997 6,400
M10000 to M17497 6,000 M10000 to M21247 9,000
Special internal relay M8000 to M8317 256 M8000 to M9997 1,600
Shift register R0 to R255 256 R0 to R255 256
Timer preset value TP0 to TP1023 1,024 TP0 to TP1999 2,000
Counter preset value CP0 to CP511 512 CP0 to CP511 512
Data register
D0 to D7999 8,000 D0 to D7999 8,000
D10000 to D55999 46,000 D10000 to D61999 52,000
Special data register D8000 to D8499 500 D8000 to D8899 900
Non-retentive data
register
- - D70000 to D269999 200,000
"(Value of device address)",
"(Value of device address number + 1)",
"(Value of device address number + 2)",
.
.
.
"(Value of device address number + (
n -1))",
Number of data ( n )
