IDEC MICROSmart FC6A Series User Manual

2: P RODUCT S PECIFICATIONS
2-36 FC6A S ERIES MICROS MART U SER ’ S M ANUAL FC9Y-B1722
Applicable connector
(2) Sensor power terminals, input terminals
DC Sink Input Wiring
DC Source Input Wiring
(3) Output terminals
Relay Output
40-I/O Type: Screw fastened type: FC6A-C40R1AE, FC6A-C40R1AEJ
Push-in type: FC6A-C40R4AE, FC6A-C40R4AEJ
(1) Power supply terminals
Screw fastened type FC6A-PMTD03PN02
Push-in type (AC) FC6A-PMSDA03PN02
(2) Sensor power terminals, input terminals
Screw fastened type FC6A-PMTA09PN02
Push-in type FC6A-PMSA09PN02
(3) Output terminals
Screw fastened type FC6A-PMTA10PN02
Push-in type FC6A-PMSA10PN02
Screw fastened type Push-in type (1) Power supply
terminals
(2)
(3)
(1)
(2)
(3)
(1)
AC Power Input
L N PE
: Fuse
: Load
L
+24V 0V COM I0 I1 I2 I3 I4 I5
I6
I7 I10 I11 I12 I13 I14 I15 I16
I17
I20 I21 I22 I23 I24 I25 I26 I27
Power Output
24V DC Input 24V DC Input 24V DC Input
-
+
2-wire
Sensor
+24V
0V COM
I0 I1 I2 I3 I4 I5
I6
I7 I10 I11 I12 I13 I14 I15 I16
I17
I20 I21 I22 I23 I24 I25 I26 I27
Power Output
24V DC Input 24V DC Input 24V DC Input
+
-
2-wire
Sensor
Relay Output
Q10
Q11 Q12 Q13 COM3COM2 Q14 Q15 Q16 Q17
Relay Output
Q0
Q1 Q2 Q3 COM1COM0 Q4 Q5 Q6 Q7
LLLL
-
+
LLLL
-
+
