MorphoWave Compact - 2018_2000035853
RFID cards (depending
on product version)
MIFARE Plus SL1 cards
DESFire 3DES legacy 2K, 4K and 8K (EV0 & EV1)
DESFire AES 2k, 4k, 8k (EV1)
All HID iClass cards (incl. iClass legacy, iClass SR and iClass
SE), except 2K2
HID Prox 125 kHz whatever the format (26, 37 ....)
Serial port
The serial port supports WIEGAND, DATACLOCK (ISO2),
RS422 and RS485 protocols
GPIO
3 GPI, 3 GPO
Output relay switches
Access granted: 1 switch two outputs (normally “open” and
normally “closed”)
30V – 1A max (Resistive loads, 100 000 cycles)
USB host port
terminal configuration through a USB mass storage key
connection with an external Wi-Fi™ USB dongle using an
adapter cable
Input signals
LED1/LED2 to activate the access granted relay
Power supply
12 to 24 V DC power supply (2.5A min @12V)
Or by Power Over Ethernet through RJ-45 connector
Note for UL 294 Compliance power supply shall be UL 294 and
UL 294B with power limited output
Security of the terminal
Anti-tamper-pulling switches
Tamper-pulling detection: one switch closed when product wall
mounted, open when pulled out
Size and weight
W x H x D: 152 mm x 250 mm x 220 mm
(6.98” x 9.84” x 8.66”)
Weight : ~ 2 kg
Environmental
conditions
Operating temperature:
-10 °C to + 55 °C (14°F to 131°F) when ECO-mode is ON
