Idemia MorphoWave Compact - Wi-Fi Dongle Installation

57
MorphoWave Compact - 2018_2000035853
Then plug the Wi-Fi
TM
dongle on the provided cable, connect the cable on the Mini-USB socket, and fit the
dongle inside the hole, as described on the following picture:
2. connect
1. connect
3. Insert the
dongle in the hole
4. Attach the cover and
tighten the screws
Figure 24: Wi-Fi™ dongle installation
Close the product with the cover and tighten the 4 screws.
